Saab 9-5 I facelift 2 (2005-2010) transmission control module connector a Wiring diagrams
This page contains all the electrical diagrams for the component. transmission control module connector a, in which he is found in the car Saab 9-5 I facelift 2 (2005-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram transmission control module connector a (1 of 2)
ACC CONTROL MODULE
ANTI-THEFT FOG LIGHTS ALARM SIREN, RELAY A/C COMPRESSOR RELAY
AUDIO SYSTEM AMPLIFIER
BATTERY
BLK WIRE
BLU WIRE
BRAKE LIGHT SWITCH
DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH)
DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) FUSE 17
DICE CONTROL MODULE
DICE CONTROL MODULE, ACC CONTROL MODULE, DIP SWITCH
DICE CONTROL MODULE, SID, SPA CONTROL MODULE, COOLANT CIRCULATION PUMP MOTOR
DIPPED BEAM RELAY
ELECTRICALLY ADJUSTABLE PASSENGER'S SEAT RELAY
ELECTRICALLY HEATED REAR WINDOW RELAY
ELECTRONIC ROAD TOLL CONNECTOR, ONSTAR CONTROL MODULE
ENGINE BAY MAIN FUSE BOX (BEHIND BATTERY)
ENGINE BAY MAXI FUSES BOX (BEHIND MAIN FUSE BOX IN
ENGINE BAY)
ENGINE LIGHT CONTROL SWITCH SYSTEM MAIN RELAY
ESP CONTROL MODULE
FUSE
FUSE 1
FUSE 10
FUSE 11
FUSE 12
FUSE 13
FUSE 16
FUSE 17 FUSE 14
FUSE 18
FUSE 20
FUSE 22
FUSE 23
FUSE 25 FUSE 39
FUSE 38
FUSE 6 FUSE 15
FUSE 8
FUSE 9
GENERATOR
GLOW PLUG CONTROL MODULE
GRN WIRE
GRY WIRE
LOW SPEED 2 RADIATOR FANS RELAY, LEFT HIGH SPEED RADIATOR FAN RELAY
MAIN BEAM RELAY
MAXI FUSE 1
MAXI FUSE 2
MAXI FUSE 3
MAXI FUSE 4
MAXI FUSE 5
NCA WIRE
PMM CONTROL MODULE, TWICE CONTROL MODULE, MOBILE TELEPHONE/ ONSTAR CONNECTOR
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT HIGH HORN RELAY SPEED RADIATOR FAN RELAY
STARTER MOTOR
STARTER MOTOR INTERLOCK CLUTCH SWITCH
STARTER RELAY
TO IGNITION SWITCH (DIAGRAM 2 OF 2)
TO IGNITION SWITCH RELAY (DIAGRAM 2 OF 2)
TOW BAR CONNECTOR
TRANSMISSION CONTROL MODULE CONNECTOR A
VENTILATION FAN MOTOR
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 2) -> TRANSMISSION CONTROL MODULE CONNECTOR A
Wiring diagram transmission control module connector a (2 of 2)
A/T
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLU WIRE
BRN/YEL WIRE
DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) FUSE 37
DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) FUSE 5
ENGINE BAY MAIN FUSE BOX (BEHIND BATTERY)
ESP CONTROL MODULE, YAW RATE SENSOR (W/ ESP)
FROM MAXI FUSE 4 (DIAGRAM 1 OF 2)
FROM MAXI FUSE 5 (DIAGRAM 1 OF 2)
FRONT CIGARETTE LIGHTER
FUSE
FUSE 16
FUSE 19
FUSE 2
FUSE 21
FUSE 24
FUSE 26
FUSE 28 FUSE 27
FUSE 29
FUSE 30
FUSE 31
FUSE 33 FUSE 35
FUSE 34
FUSE 9
FUSE FUSE 6 FUSE 36
GRN WIRE
GRY WIRE
HIGH PRESSURE HEADLAMP WASHER FLUID PUMP RELAY
IGNITION SWITCH
IGNITION SWITCH RELAY (IN DASHBOARD MAIN RELAY BOX)
KEY-IN IGNITION SWITCH
LIGHT DIRECTION SWITCH INDICATORS SWITCH
LIGHT SWITCH
LOCK OFF
MOBILE TELEPHONE/ ONSTAR CONNECTOR
PPS CONTROL MODULE, ACC CONTROL MODULE, SRS/AIR BAG CONTROL MODULE
REAR CIGARETTE LIGHTER
REAR WINDOW WIPER SWITCH, REAR INTERMITTENT WIPER RELAY, REAR WINDOW WIPER MOTOR
RED/GRN WIRE
RED/WHT WIRE
STARTER RELAY, TRANSMISSION RANGE SWITCH 2 (A/T), AUDIO SYSTEM MAIN UNIT
STEERING WHEEL ANGLE SENSOR (W/ ESP)
TRANSMISSION CONTROL MODULE CONNECTOR A
TWICE CONTROL MODULE, DICE CONTROL MODULE
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 2) -> TRANSMISSION CONTROL MODULE CONNECTOR A
