Saab 9-5 I facelift 2 (2005-2010) steering wheel switch unit Wiring diagrams

BLK WIRE BLK/BLU WIRE BRN/GRY WIRE BRN/WHT WIRE ENGINE BAY MAIN FUSE BOX (BEHIND BATTERY) FUSE 17 HORN RELAY (IN ENGINE BAY HORN SWITCH HOT AT ALL TIMES LEFT HORN (BEHIND LEFT SIDE OF GRILL) MAIN RELAY BOX) NCA WIRE RED/YEL WIRE RIGHT HORN SID CONTROL MODULE (ON REAR OF INSTRUMENT CLUSTER) STEERING WHEEL HORN/SWITCHES CONTACT UNIT (IN STEERING WHEEL, UNDER CRASH PAD) STEERING WHEEL SWITCH UNIT VIO/WHT WIRE W/ STEERING WHEEL AUDIO CONTROLS

BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM COOLANT LEVEL SWITCH (IN COOLANT EXPANSION TANK) FRONT LAMPS FILAMENT MONITOR GRN WIRE GRY WIRE HORN SWITCH INSTRUMENT LIGHTING RHEOSTAT LEFT FRONT DOOR SWITCH (IN LEFT FRONT B PILLAR) LEFT REAR DOOR SWITCH (AT BOTTOM OF LEFT REAR DOOR OPENING) NCA WIRE NIGHT PANEL SWITCH PRESET RED/WHT WIRE RIGHT FRONT DOOR SWITCH (IN RIGHT FRONT "B" PILLAR) RIGHT REAR DOOR SWITCH (AT BOTTOM OF RIGHT REAR DOOR OPENING) SEEK BACK SEEK BACK VOL UP SEEK FWD SEEK FWD SELECT SELECT SET CLR SET- SHIFT UP SHIFT DOWN STEERING WHEEL HORN/ SWITCHES CONTACT UNIT (IN STEERING WHEEL, UNDER CRASH PAD) STEERING WHEEL SWITCH UNIT TWICE CONTROL MODULE (UNDER DRIVER'S SEAT) VIO/BRN WIRE VIO/WHT WIRE VOL CLR VOL DOWN VOL DOWN PRESET VOL UP W/ SHIFT W/O SHIFT WARNING SYSTEM TRANSMISSIONS SYSTEM COMPUTER DATA LINES SYSTEM HORNS SYSTEM WASHER FLUID LEVEL SWITCH (IN WASHER FLUID RESERVOIR) WHT WIRE WHT/BLK WIRE WHT/GRY WIRE YEL WIRE YEL/GRY WIRE YEL/WHT WIRE

BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) GRN WIRE GRY WIRE HORNS SYSTEM HOT AT ALL TIMES FUSE 9 HOT IN ON OR START FUSE 21 INSTRUMENT CLUSTER MOBILE TELEPHONE CONNECTOR NCA WIRE ONSTAR ORG/ WIRE POWER DISTRIBUTION SYSTEM RADIO/NAVIGATION MAIN UNIT REAR CD CHANGER (AT LEFT REAR OF LUGGAGE COMPT) RED/GRY WIRE RED/WHT BLK WIRE RED/WHT WIRE SEEK SEEK DOWN FWD SEEK SEEK UP BACK SELECT VOL DOWN SID CONTROL MODULE (ON REAR OF STEERING WHEEL HORN/SWITCHES CONTACT UNIT (IN STEERING WHEEL, UNDER CRASH PAD) STEERING WHEEL SWITCH UNIT VIO/WHT WIRE VIO/YEL WIRE VOL UP PRESET WHT WIRE YEL WIRE

BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) GRN WIRE GRY WIRE HORNS SYSTEM HOT AT ALL TIMES FUSE 9 HOT IN ON OR START FUSE 21 INSTRUMENT CLUSTER MOBILE TELEPHONE CONNECTOR NCA WIRE ONSTAR ORG/ WIRE POWER DISTRIBUTION SYSTEM RADIO/NAVIGATION MAIN UNIT REAR CD CHANGER (AT LEFT REAR OF LUGGAGE COMPT) RED/GRY WIRE RED/WHT BLK WIRE RED/WHT WIRE SEEK SEEK DOWN FWD SEEK SEEK UP BACK SELECT VOL DOWN SID CONTROL MODULE (ON REAR OF STEERING WHEEL HORN/SWITCHES CONTACT UNIT (IN STEERING WHEEL, UNDER CRASH PAD) STEERING WHEEL SWITCH UNIT VIO/WHT WIRE VIO/YEL WIRE VOL UP PRESET WHT WIRE YEL WIRE

4 7 16 MOBILE TELEPHONE CONNECTOR AUDIO SYSTEM MAIN UNIT BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/BLU WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) FUSE 13 FUSE 9 GRN WIRE GRY WIRE GRY/BLK WIRE HORNS SYSTEM HOT AT ALL TIMES NCA WIRE ONSTAR ORG/ WIRE PRESET RED/BLU WIRE RED/GRY WIRE SATELLITE RADIO ANTENNA SATELLITE RADIO RECEIVER (UNDER RIGHT SIDE OF PARCEL SHELF) SEEK SEEK DOWN FWD SEEK SEEK UP BACK SELECT SID CONTROL MODULE (ON REAR OF INSTRUMENT CLUSTER) STARTING/ CHARGING SYSTEM STEERING WHEEL HORN/SWITCHES CONTACT UNIT (IN STEERING WHEEL, UNDER CRASH PAD) STEERING WHEEL SWITCH UNIT TELCO VIO/WHT WIRE VOL DOWN VOL UP WHT WIRE YEL WIRE YEL/VIO WIRE
