Saab 9-5 I facelift 2 (2005-2010) simultaneous central locking switch Wiring diagrams

BLK WIRE BLK/WHT WIRE BLU/WHT WIRE BRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM CONTROL MODULE DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) DOOR MIRROR RETRACTION SWITCH ELECTRIC WINDOW LIFT SWITCH UNIT ENGINE BAY MAXI FUSES BOX (BEHIND MAIN FUSE BOX IN ENGINE BAY) ESP SWITCH FOGLIGHTS SWITCH FRONT ASHTRAY, CIGARETTE LIGHTER LAMP FUSE 3 FUSE 35 FUSE 4 FUSE 8 GRN WIRE HAZARD FLASHER SWITCH HEAD PARK OFF HEADLAMP LEVELLING SWITCH HOT AT ALL TIMES HOT IN IGNITION SWITCH INSTRUMENT LIGHTING RHEOSTAT LIGHT SWITCH MAIN INSTRUMENT UNIT MAXI FUSE 2 NCA WIRE NIGHT PANEL (LEFT CENTER SWITCH OF DASH, BEHIND RADIO) REAR ASHTRAY, CIGARETTE LIGHTER LAMP REAR SEAT HEATING PAD SWITCH RED WIRE RED/GRY WIRE RED/WHT WIRE RUN WIRE SELECTOR LEVER POSITION INDICATOR LAMP SELECTOR LEVER, SHIFT LOCK SOLENOID (IN CENTER CONSOLE) SID CONTROL MODULE (ON REAR OF INSTRUMENT CLUSTER) SIMULTANEOUS CENTRAL LOCKING SWITCH TWICE CONTROL MODULE (UNDER DRIVER'S SEAT) VIO/GRY WIRE WHT RED/ WIRE WHT WIRE YEL WIRE YEL/GRY WIRE

BLK WIRE BLK/WHT WIRE BLU/VIO WIRE BLU/WHT WIRE BRN/WHT WIRE BRN/YEL WIRE DRIVER CENTRAL LOCKING SYSTEM MOTOR (IN REAR OF LEFT FRONT DOOR) FUSE 10 GRN/BLK WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT AT ALL TIMES DASHBOARD MAIN FUSE BOARD FUSE 23 (BEHIND LEFT END OF DASH) LEFT REAR CENTRAL LOCKING SYSTEM MOTOR (IN LEFT REAR DOOR) PASSENGER CENTRAL LOCKING SYSTEM MOTOR (IN REAR OF RIGHT FRONT DOOR) RED YEL/ WIRE RED/BLU WIRE RED/YEL WIRE RIGHT REAR CENTRAL LOCKING SYSTEM MOTOR (IN RIGHT REAR DOOR) SIMULTANEOUS CENTRAL LOCKING SWITCH TWICE CONTROL MODULE (UNDER DRIVER'S SEAT) WHT/ BLK WIRE WHT/GRY WIRE WHT/RED WIRE YEL RED/ WIRE YEL/BRN WIRE YEL/GRY WIRE
