Saab 9-5 I facelift 2 (2005-2010) red Wiring diagrams

This page contains all the electrical diagrams for the component. red, in which he is found in the car Saab 9-5 I facelift 2 (2005-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram red (11 of 28)

Wiring diagram red for Saab 9-5 I facelift 2 (2005-2010) (11 of 28)

Get access

A/T BLK WIRE BLK/YEL WIRE BLU WIRE BRN WIRE DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) DRIVER'S SIDE DOOR MIRROR FUSE 2 FUSE 21 GRN WIRE GRN/WHT WIRE GRY WIRE HOT IN HOT IN RUN OR START INTERIOR REAR VIEW MIRROR M/T NCA WIRE NEUTRAL POSITION SWITCH 2 PASSENGER'S SIDE DOOR MIRROR REAR LIGHT SWITCH RED WIRE RUN WIRE VIO WIRE WHT WIRE YEL WIRE YEL/WHT WIRE

Go to component -> Automatic day/night mirror circuit -> RED WIRE

Wiring diagram red (12 of 28)

Wiring diagram red for Saab 9-5 I facelift 2 (2005-2010) (12 of 28)

Get access

BATTERY BLK WIRE BLU WIRE BLU/WHT WIRE BRN WIRE CHARGE INDICATOR DASHBOARD FUSE 27 MAIN FUSE BOARD (BEHIND LEFT END OF DASH) GENERATOR D+ IGNITION SWITCH LOCK OFF MAIN INSTRUMENT UNIT MAXI FUSE 4 NCA WIRE POWER DISTRIBUTION SYSTEM RED WIRE RED/WHT WIRE STARTER MOTOR (ON TRANSMISSION) VIO WIRE VIO/YEL WIRE WHT WIRE

Go to component -> Charging circuit -> RED WIRE

Wiring diagram red (13 of 28)

Wiring diagram red for Saab 9-5 I facelift 2 (2005-2010) (13 of 28)

Get access

ACC CONTROL MODULE BACKREST SEAT HEATING PAD BLK WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/BLU WIRE BRN/GRY WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE CUSHION SEAT HEATING PAD DRIVER SEAT HEATING PAD ELEC- TRICALLY HEATED REAR SEAT RELAY (IN DASHBOARD MAIN RELAY BOX) FUSE 10 FUSE 21 GRN/RED WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT AT ALL TIMES DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) FUSE 38 HOT IN RUN OR START ILLUM LEFT REAR SEAT HEATING PAD NCA WIRE PASSENGER'S SEAT HEATING PAD REAR SEAT HEATED PAD SWITCH RED WIRE RED/WHT WIRE RED/YEL WIRE RIGHT REAR SEAT HEATING PAD SEAT HEATING PAD TEMPERATURE SENSOR TWICE CONTROL MODULE (UNDER DRIVER'S SEAT) VIO BRN/ WIRE VIO/YEL WIRE WHT WIRE WHT/GRY WIRE YEL WIRE YEL/GRY WIRE

Go to component -> Heated seats circuit -> RED WIRE

Wiring diagram red (14 of 28)

Wiring diagram red for Saab 9-5 I facelift 2 (2005-2010) (14 of 28)

Get access

BLK WIRE BLK/WHT WIRE BLU/WHT WIRE BRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM CONTROL MODULE DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) DOOR MIRROR RETRACTION SWITCH ELECTRIC WINDOW LIFT SWITCH UNIT ENGINE BAY MAXI FUSES BOX (BEHIND MAIN FUSE BOX IN ENGINE BAY) ESP SWITCH FOGLIGHTS SWITCH FRONT ASHTRAY, CIGARETTE LIGHTER LAMP FUSE 3 FUSE 35 FUSE 4 FUSE 8 GRN WIRE HAZARD FLASHER SWITCH HEAD PARK OFF HEADLAMP LEVELLING SWITCH HOT AT ALL TIMES HOT IN IGNITION SWITCH INSTRUMENT LIGHTING RHEOSTAT LIGHT SWITCH MAIN INSTRUMENT UNIT MAXI FUSE 2 NCA WIRE NIGHT PANEL (LEFT CENTER SWITCH OF DASH, BEHIND RADIO) REAR ASHTRAY, CIGARETTE LIGHTER LAMP REAR SEAT HEATING PAD SWITCH RED WIRE RED/GRY WIRE RED/WHT WIRE RUN WIRE SELECTOR LEVER POSITION INDICATOR LAMP SELECTOR LEVER, SHIFT LOCK SOLENOID (IN CENTER CONSOLE) SID CONTROL MODULE (ON REAR OF INSTRUMENT CLUSTER) SIMULTANEOUS CENTRAL LOCKING SWITCH TWICE CONTROL MODULE (UNDER DRIVER'S SEAT) VIO/GRY WIRE WHT RED/ WIRE WHT WIRE YEL WIRE YEL/GRY WIRE

Go to component -> Instrument illumination circuit -> RED WIRE

Wiring diagram red (15 of 28)

Wiring diagram red for Saab 9-5 I facelift 2 (2005-2010) (15 of 28)

Get access

1 2 3 4 (PIN 5-17 NOT USED) 18 19 20 21 22 23 24 25 26 BACKWARD BLK WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DASH BOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) DOWN DRIVER'S SEAT BACKREST ADJUSTMENT POSITION SENSOR/MOTOR DRIVER'S SEAT FRONT HEIGHT ADJUSTMENT POSITION SENSOR/MOTOR DRIVER'S SEAT LEGROOM ADJUSTMENT POSITION SENSOR/MOTOR DRIVER'S SEAT REAR HEIGHT ADJUSTMENT POSITION SENSOR/MOTOR ELECTRICALLY ADJUSTABLE DRIVER'S SEAT SWITCH FORWARD/ FUSE 25 FUSE 26 GRN WIRE GRN/WHT WIRE GRY WIRE GRY/BRN WIRE HOT AT ALL TIMES HOT IN RUN OR START LAYBACK MOTOR ORG/ WIRE POSITION SENSOR REAR RED WIRE RED/WHT WIRE UP FRONT UPRIGHT VIO/GRN WIRE WHT WIRE YEL WIRE YEL/WHT WIRE

Go to component -> Memory seat circuit -> RED WIRE

Wiring diagram red (16 of 28)

Wiring diagram red for Saab 9-5 I facelift 2 (2005-2010) (16 of 28)

Get access

ACC CONTROL MODULE ANTI-THEFT FOG LIGHTS ALARM SIREN, RELAY A/C COMPRESSOR RELAY AUDIO SYSTEM AMPLIFIER BATTERY BLK WIRE BLU WIRE BRAKE LIGHT SWITCH DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) FUSE 17 DICE CONTROL MODULE DICE CONTROL MODULE, ACC CONTROL MODULE, DIP SWITCH DICE CONTROL MODULE, SID, SPA CONTROL MODULE, COOLANT CIRCULATION PUMP MOTOR DIPPED BEAM RELAY ELECTRICALLY ADJUSTABLE PASSENGER'S SEAT RELAY ELECTRICALLY HEATED REAR WINDOW RELAY ELECTRONIC ROAD TOLL CONNECTOR, ONSTAR CONTROL MODULE ENGINE BAY MAIN FUSE BOX (BEHIND BATTERY) ENGINE BAY MAXI FUSES BOX (BEHIND MAIN FUSE BOX IN ENGINE BAY) ENGINE LIGHT CONTROL SWITCH SYSTEM MAIN RELAY ESP CONTROL MODULE FUSE FUSE 1 FUSE 10 FUSE 11 FUSE 12 FUSE 13 FUSE 16 FUSE 17 FUSE 14 FUSE 18 FUSE 20 FUSE 22 FUSE 23 FUSE 25 FUSE 39 FUSE 38 FUSE 6 FUSE 15 FUSE 8 FUSE 9 GENERATOR GLOW PLUG CONTROL MODULE GRN WIRE GRY WIRE LOW SPEED 2 RADIATOR FANS RELAY, LEFT HIGH SPEED RADIATOR FAN RELAY MAIN BEAM RELAY MAXI FUSE 1 MAXI FUSE 2 MAXI FUSE 3 MAXI FUSE 4 MAXI FUSE 5 NCA WIRE PMM CONTROL MODULE, TWICE CONTROL MODULE, MOBILE TELEPHONE/ ONSTAR CONNECTOR RED WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT HIGH HORN RELAY SPEED RADIATOR FAN RELAY STARTER MOTOR STARTER MOTOR INTERLOCK CLUTCH SWITCH STARTER RELAY TO IGNITION SWITCH (DIAGRAM 2 OF 2) TO IGNITION SWITCH RELAY (DIAGRAM 2 OF 2) TOW BAR CONNECTOR TRANSMISSION CONTROL MODULE CONNECTOR A VENTILATION FAN MOTOR VIO WIRE WHT WIRE YEL WIRE

Go to component -> Power distribution circuit (1 of 2) -> RED WIRE

Wiring diagram red (17 of 28)

Wiring diagram red for Saab 9-5 I facelift 2 (2005-2010) (17 of 28)

Get access

BACKREST ADJUSTMENT MOTOR, BLK WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) DOWN ELECTRICALLY ADJUSTABLE DRIVER'S SEAT RELAY (UNDER DRIVER'S SEAT CUSHION) ELECTRICALLY ADJUSTABLE DRIVER'S SEAT SWITCH ELECTRICALLY ADJUSTABLE PASSENGER'S SEAT RELAY (UNDER PASSENGER'S SEAT CUSHION) ELECTRICALLY ADJUSTABLE PASSENGER'S SEAT SWITCH FRONT FRONT HEIGHT ADJUSTMENT MOTOR GRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES FUSE 11 HOT AT ALL TIMES FUSE 25 LEG ROOM ADJUSTMENT MOTOR NCA WIRE REAR REAR (UNDER HEIGHT DRIVER'S ADJUSTMENT SEAT) MOTOR REAR HEIGHT ADJUSTMENT MOTOR RED WIRE TWICE CONTROL MODULE (UNDER DRIVER'S SEAT) UP DOWN WHT RED/ WIRE WHT/ BLK WIRE YEL WIRE YEL/WHT WIRE

Go to component -> Power seats circuit -> RED WIRE

Wiring diagram red (18 of 28)

Wiring diagram red for Saab 9-5 I facelift 2 (2005-2010) (18 of 28)

Get access

BLK WIRE BLU/VIO WIRE DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) ELECTRICALLY OPERATED SUN ROOF MOTOR (IN FRONT OF SUN ROOF CARTRIDGE) ELECTRICALLY OPERATED SUN ROOF SWITCH FUSE 10 FUSE 26 GRN WIRE GRN/GRY WIRE HOT AT ALL TIMES HOT IN ON OR START RED WIRE RED/YEL WIRE VIO WIRE VIO/GRN WIRE YEL WIRE YEL/WHT WIRE

Go to component -> Power top/sunroof circuit -> RED WIRE

Wiring diagram red (19 of 28)

Wiring diagram red for Saab 9-5 I facelift 2 (2005-2010) (19 of 28)

Get access

ACC CONTROL MODULE BLK WIRE GRN WIRE GRY WIRE HOT AT ALL TIMES DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) FUSE 20 LEFT SEAT BACKREST VENTILATION FAN MOTOR (IN LEFT FRONT SEAT BACK) LEFT SEAT SQUAB VENTILATION FAN MOTOR ORG/ WIRE RED WIRE RED/GRY WIRE RIGHT SEAT BACKREST VENTILATION FAN MOTOR (IN RIGHT FRONT SEAT BACK) RIGHT SEAT SQUAB VENTILATION FAN MOTOR VIO/WHT WIRE WHT WIRE

Go to component -> Seat ventilation circuit -> RED WIRE

Wiring diagram red (20 of 28)

Wiring diagram red for Saab 9-5 I facelift 2 (2005-2010) (20 of 28)

Get access

BLK WIRE BRAKE LIGHT SWITCH (ON PEDAL BRACKET) BRN WIRE DASH BOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) FUSE 1 GRN WIRE GRY WIRE HOT AT ALL TIMES NCA WIRE RED WIRE SELECTOR LEVER MICROSWITCH SELECTOR LEVER, SHIFT LOCK SOLENOID (IN CENTER CONSOLE) TRANSMISSIONS SYSTEM YEL WIRE

Go to component -> Shift interlock circuit -> RED WIRE

Page 2 of 3

1 2 3

Saab 9-5 I facelift 2 (2005-2010) red Wiring diagrams

Wiring diagram red (11 of 28)

List of components:

Wiring diagram red (12 of 28)

List of components:

Wiring diagram red (13 of 28)

List of components:

Wiring diagram red (14 of 28)

List of components:

Wiring diagram red (15 of 28)

List of components:

Wiring diagram red (16 of 28)

List of components:

Wiring diagram red (17 of 28)

List of components:

Wiring diagram red (18 of 28)

List of components:

Wiring diagram red (19 of 28)

List of components:

Wiring diagram red (20 of 28)

List of components:
