Saab 9-5 I facelift 2 (2005-2010) red/ wht Wiring diagram

A/C COMPRESSOR (RIGHT FRONT OF ENGINE) A/C COMPRESSOR RELAY (IN ENGINE BAY MAIN RELAY BOX) A/C PRESSURE SENSOR (ON BOTTOM RIGHT SIDE OF CONDENSER) ACC CONTROL MODULE AIR COMPARTMENT TEMPERATURE SENSOR BLEND AIR FLAP MOTOR (LEFT) (ON LEFT END OF HEATING, VENTILATION UNIT) BLEND AIR FLAP MOTOR (RIGHT) (ON RIGHT END OF HEATING, VENTILATION UNIT) BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/GRY WIRE BLU/WHT WIRE BRN WIRE BRN YEL/ WIRE BRN/GRN WIRE BRN/ORG WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM COOLANT TEMPERATURE SENSOR DICE CONTROL MODULE (ON MAIN RELAY BOX IN DASHBOARD) ENGINE BAY MAIN FUSE BOX (BEHIND BATTERY) FUSE 14 FUSE 6 GRN WIRE GRN/ BLU WIRE GRN/ YEL WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/RED WIRE GRN/VIO WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) FUSE 22 HOT AT ALL TIMES FUSE 20 HOT AT ALL TIMES FUSE 8 HOT IN ON FUSE 31 HOT IN ON OR START FUSE 26 HOT W/ MAIN RELAY ENERGIZED NCA WIRE ORG/ WIRE ORG/WHT WIRE RED WIRE RED/ BLU WIRE RED/ VIO WIRE RED/ WHT WIRE RED/BLU WIRE RED/BRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE SEATS SYSTEM SOLAR SENSOR (ON TOP CENTER OF DASH) SOLID STATE TRIONIC ENGINE CONTROL MODULE (IN RIGHT REAR OF ENGINE COMPT) VENTILATION FAN MOTOR (IN TOP OF HEATING, VENTILATION UNIT) VIO WIRE VIO/ BLK WIRE VIO/ WHT WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/WHT WIRE WHT WIRE WHT YEL/ WIRE WHT/ BLK WIRE WHT/ BLU WIRE WHT/GRY WIRE YEL BRN/ WIRE YEL WIRE YEL/ WHT WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/WHT WIRE
