Saab 9-5 I facelift 2 (2005-2010) rear lockout switch Wiring diagram
This page shows the only wiring diagram for the component.rear lockout switch, which is found in the car Saab 9-5 I facelift 2 (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear lockout switch (1 of 1)
BLK/WHT WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/VIO WIRE
DASH BOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH)
DRIVER'S SIDE ELECTRIC WINDOW LIFT MOTOR (IN LEFT FRONT DOOR)
ELECTRIC WINDOWS/ ELECTRIC SUNROOF SWITCH UNIT
FUSE 36
FUSE 6
GRN WIRE
GRN/BLU WIRE
GRN/GRY WIRE
GRN/VIO WIRE
HOT IN RUN
LEFT REAR ELECTRIC WINDOW LIFT MOTOR (IN LEFT REAR DOOR)
LEFT REAR ELECTRIC WINDOW LIFT SWITCH
LEFT REAR SWITCH
PASSENGER'S SIDE ELECTRIC WINDOW LIFT MOTOR (IN RIGHT FRONT DOOR)
REAR LOCKOUT SWITCH
RIGHT REAR ELECTRIC WINDOW LIFT MOTOR (IN RIGHT REAR DOOR)
RIGHT REAR ELECTRIC WINDOW LIFT SWITCH
RIGHT REAR SWITCH
SOLID STATE
WHT WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> Power windows circuit -> REAR LOCKOUT SWITCH
