Saab 9-5 I facelift 2 (2005-2010) radio/navigation main unit Wiring diagrams
This page contains all the electrical diagrams for the component. radio/navigation main unit, in which he is found in the car Saab 9-5 I facelift 2 (2005-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
radio/navigation main unit wiring diagram (1 of 2)
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH)
GRN WIRE
GRY WIRE
HORNS SYSTEM
HOT AT ALL TIMES FUSE 9
HOT IN ON OR START FUSE 21
INSTRUMENT CLUSTER
MOBILE TELEPHONE CONNECTOR
NCA WIRE
ONSTAR
ORG/ WIRE
POWER DISTRIBUTION SYSTEM
RADIO/NAVIGATION MAIN UNIT
REAR CD CHANGER (AT LEFT REAR OF LUGGAGE COMPT)
RED/GRY WIRE
RED/WHT BLK WIRE
RED/WHT WIRE
SEEK SEEK DOWN FWD
SEEK SEEK UP BACK
SELECT VOL DOWN
SID CONTROL MODULE (ON REAR OF
STEERING WHEEL HORN/SWITCHES CONTACT UNIT (IN STEERING WHEEL, UNDER CRASH PAD)
STEERING WHEEL SWITCH UNIT
VIO/WHT WIRE
VIO/YEL WIRE
VOL UP PRESET
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit (1 of 2) -> RADIO/NAVIGATION MAIN UNIT
radio/navigation main unit wiring diagram (2 of 2)
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH)
GRN WIRE
GRY WIRE
HORNS SYSTEM
HOT AT ALL TIMES FUSE 9
HOT IN ON OR START FUSE 21
INSTRUMENT CLUSTER
MOBILE TELEPHONE CONNECTOR
NCA WIRE
ONSTAR
ORG/ WIRE
POWER DISTRIBUTION SYSTEM
RADIO/NAVIGATION MAIN UNIT
REAR CD CHANGER (AT LEFT REAR OF LUGGAGE COMPT)
RED/GRY WIRE
RED/WHT BLK WIRE
RED/WHT WIRE
SEEK SEEK DOWN FWD
SEEK SEEK UP BACK
SELECT VOL DOWN
SID CONTROL MODULE (ON REAR OF
STEERING WHEEL HORN/SWITCHES CONTACT UNIT (IN STEERING WHEEL, UNDER CRASH PAD)
STEERING WHEEL SWITCH UNIT
VIO/WHT WIRE
VIO/YEL WIRE
VOL UP PRESET
WHT WIRE
YEL WIRE
Go to component -> Premium radio circuit, with navigation (1 of 2) -> RADIO/NAVIGATION MAIN UNIT
