Saab 9-5 I facelift 2 (2005-2010) passenger courtesy lighting lamp Wiring diagram
This page shows the only wiring diagram for the component.passenger courtesy lighting lamp, which is found in the car Saab 9-5 I facelift 2 (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger courtesy lighting lamp (1 of 1)
BLK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/YEL WIRE
CABIN LIGHT SWITCH
CENTER FRONT READING LAMP
CENTER ROOF LAMP
COMPUTER DATA LINES SYSTEM
DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH)
DOOR DOOR (IN LUGGAGE COMPT, UNDER LEFT LIGHT ASSEMBLY)
DRIVER COURTESY LIGHTING LAMP
FRONT DOME LIGHT UNIT
FRONT ROOF LAMP
FUSE 10
FUSE 20
FUSE 8
GLOVE COMPARTMENT LAMP
GRN WIRE
GRN/GRY WIRE
GRY WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR SWITCH
LEFT FRONT FLOOR LIGHTING LAMP
LEFT REAR DOOR SWITCH (AT BOTTOM OF LEFT REAR DOOR OPENING)
LEFT VANITY MIRROR LAMP
LUGGAGE COMPARTMENT LIGHTING LAMP
NCA WIRE
PASSENGER COURTESY LIGHTING LAMP
REAR DOME LIGHT UNIT
REAR READING LAMP
RED WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT DOOR SWITCH
RIGHT FRONT FLOOR LIGHTING LAMP
RIGHT REAR DOOR SWITCH (AT BOTTOM OF RIGHT REAR DOOR OPENING)
RIGHT VANITY MIRROR LAMP
TWICE CONTROL MODULE (UNDER DRIVER'S SEAT)
UNDER LEFT LIGHT ASSEMBLY) (4 DOOR)
WHT WIRE
WHT/GRY WIRE
YEL WIRE
Go to component -> Courtesy lamp circuit -> PASSENGER COURTESY LIGHTING LAMP
