Saab 9-5 I facelift 2 (2005-2010) light direction switch indicators switch Wiring diagram
This page shows the only wiring diagram for the component.light direction switch indicators switch, which is found in the car Saab 9-5 I facelift 2 (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram light direction switch indicators switch (1 of 1)
A/T
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLU WIRE
BRN/YEL WIRE
DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) FUSE 37
DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) FUSE 5
ENGINE BAY MAIN FUSE BOX (BEHIND BATTERY)
ESP CONTROL MODULE, YAW RATE SENSOR (W/ ESP)
FROM MAXI FUSE 4 (DIAGRAM 1 OF 2)
FROM MAXI FUSE 5 (DIAGRAM 1 OF 2)
FRONT CIGARETTE LIGHTER
FUSE
FUSE 16
FUSE 19
FUSE 2
FUSE 21
FUSE 24
FUSE 26
FUSE 28 FUSE 27
FUSE 29
FUSE 30
FUSE 31
FUSE 33 FUSE 35
FUSE 34
FUSE 9
FUSE FUSE 6 FUSE 36
GRN WIRE
GRY WIRE
HIGH PRESSURE HEADLAMP WASHER FLUID PUMP RELAY
IGNITION SWITCH
IGNITION SWITCH RELAY (IN DASHBOARD MAIN RELAY BOX)
KEY-IN IGNITION SWITCH
LIGHT DIRECTION SWITCH INDICATORS SWITCH
LIGHT SWITCH
LOCK OFF
MOBILE TELEPHONE/ ONSTAR CONNECTOR
PPS CONTROL MODULE, ACC CONTROL MODULE, SRS/AIR BAG CONTROL MODULE
REAR CIGARETTE LIGHTER
REAR WINDOW WIPER SWITCH, REAR INTERMITTENT WIPER RELAY, REAR WINDOW WIPER MOTOR
RED/GRN WIRE
RED/WHT WIRE
STARTER RELAY, TRANSMISSION RANGE SWITCH 2 (A/T), AUDIO SYSTEM MAIN UNIT
STEERING WHEEL ANGLE SENSOR (W/ ESP)
TRANSMISSION CONTROL MODULE CONNECTOR A
TWICE CONTROL MODULE, DICE CONTROL MODULE
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 2) -> LIGHT DIRECTION SWITCH INDICATORS SWITCH
