Saab 9-5 I facelift 2 (2005-2010) left radio antenna amplifier Wiring diagrams
This page contains all the electrical diagrams for the component. left radio antenna amplifier, in which he is found in the car Saab 9-5 I facelift 2 (2005-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left radio antenna amplifier (1 of 3)
4 DOOR
4 DOOR PRESTIGE
5 DOOR
5 DOOR PRESTIGE
ANTENNA GROUND FILTER (ON LEFT "C" PILLAR)
AUDIO SYSTEM AMPLIFIER (BEHIND RIGHT KICK PANEL)
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BLU WIRE
BLU/VIO WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
CENTER DASHBOARD SPEAKER
DRIVER'S SIDE FRONT DOOR SPEAKER
GRN WIRE
GRN/BLU WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) FUSE 13
LEFT DASHBOARD SPEAKER
LEFT GLASS RADIO ANTENNA
LEFT PARCEL SHELF SPEAKER
LEFT RADIO ANTENNA AMPLIFIER
LEFT REAR DOOR SPEAKER
NCA WIRE
ORG/ WIRE
PASSENGER'S SIDE FRONT DOOR SPEAKER
RADIO ANTENNA AMPLIFIER (ON RIGHT "C" PILLAR)
RADIO WINDOW GLASS ANTENNA
RED/BLU WIRE
RIGHT DASHBOARD SPEAKER
RIGHT GLASS RADIO ANTENNA
RIGHT PARCEL SHELF SPEAKER
RIGHT RADIO ANTENNA AMPLIFIER
RIGHT REAR DOOR SPEAKER
SUBWOOFER SPEAKER
WHT WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Navigation circuit (2 of 2) -> LEFT RADIO ANTENNA AMPLIFIER
Wiring diagram left radio antenna amplifier (2 of 3)
4 DOOR
4 DOOR PRESTIGE
5 DOOR
5 DOOR PRESTIGE
ANTENNA GROUND FILTER (ON LEFT "C" PILLAR)
AUDIO SYSTEM AMPLIFIER (BEHIND RIGHT KICK PANEL)
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BLU WIRE
BLU/VIO WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
CENTER DASHBOARD SPEAKER
DRIVER'S SIDE FRONT DOOR SPEAKER
GRN WIRE
GRN/BLU WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) FUSE 13
LEFT DASHBOARD SPEAKER
LEFT GLASS RADIO ANTENNA
LEFT PARCEL SHELF SPEAKER
LEFT RADIO ANTENNA AMPLIFIER
LEFT REAR DOOR SPEAKER
NCA WIRE
ORG/ WIRE
PASSENGER'S SIDE FRONT DOOR SPEAKER
RADIO ANTENNA AMPLIFIER (ON RIGHT "C" PILLAR)
RADIO WINDOW GLASS ANTENNA
RED/BLU WIRE
RIGHT DASHBOARD SPEAKER
RIGHT GLASS RADIO ANTENNA
RIGHT PARCEL SHELF SPEAKER
RIGHT RADIO ANTENNA AMPLIFIER
RIGHT REAR DOOR SPEAKER
SUBWOOFER SPEAKER
WHT WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Premium radio circuit, with navigation (2 of 2) -> LEFT RADIO ANTENNA AMPLIFIER
Wiring diagram left radio antenna amplifier (3 of 3)
4 DOOR
4 DOOR PRESTIGE
5 DOOR
5 DOOR PRESTIGE
ANTENNA GROUND FILTER (ON LEFT "C" PILLAR)
AUDIO SYSTEM AMPLIFIER (BEHIND RIGHT KICK PANEL)
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BLU WIRE
BLU/VIO WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
CENTER DASHBOARD SPEAKER
DRIVER'S SIDE FRONT DOOR SPEAKER
GRN WIRE
GRN/BLU WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
LEFT DASHBOARD SPEAKER
LEFT GLASS RADIO ANTENNA
LEFT PARCEL SHELF SPEAKER
LEFT RADIO ANTENNA AMPLIFIER
LEFT REAR DOOR SPEAKER
NCA WIRE
ORG/ WIRE
PASSENGER'S SIDE FRONT DOOR SPEAKER
RADIO ANTENNA AMPLIFIER (ON RIGHT "C" PILLAR)
RADIO WINDOW GLASS ANTENNA
RED/BLU WIRE
RIGHT DASHBOARD SPEAKER
RIGHT GLASS RADIO ANTENNA
RIGHT PARCEL SHELF SPEAKER
RIGHT RADIO ANTENNA AMPLIFIER
RIGHT REAR DOOR SPEAKER
SUBWOOFER SPEAKER
WHT WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Premium radio circuit, without navigation (2 of 2) -> LEFT RADIO ANTENNA AMPLIFIER
