Saab 9-5 I facelift 2 (2005-2010) left high speed radiator fan relay Wiring diagrams
This page contains all the electrical diagrams for the component. left high speed radiator fan relay, in which he is found in the car Saab 9-5 I facelift 2 (2005-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left high speed radiator fan relay (1 of 2)
BLK WIRE
BLK/ GRN WIRE
BLK/GRN WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLU WIRE
BRN/ORG WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CONTROL MODULE
COOLANT CIRCULATION PUMP MOTOR (BEHIND POWER BRAKE SERVO)
DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH)
ENGINE BAY MAIN FUSE BOX (BEHIND BATTERY)
FUSE 1
FUSE 14
FUSE 38
GRN RED/ WIRE
GRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
HEAT EXCHANGER SOLENOID VALVE (ON FRONT EDGE OF HEATER HOUSING ASSEMBLY)
HOT AT ALL TIMES
LEFT HIGH SPEED RADIATOR FAN RELAY
LEFT RADIATOR FAN MOTOR (BEHIND LEFT SIDE OF RADIATOR)
LOW SPEED 2 RADIATOR FANS RELAY
RED YEL/ WIRE
RED/ VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT HIGH SPEED RADIATOR FAN RELAY
RIGHT RADIATOR FAN MOTOR (BEHIND RIGHT
SEATS SYSTEM
SIDE OF RADIATOR)
VIO GRN/ WIRE
VIO WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WHT WIRE
WHT/GRY WIRE
YEL/GRY WIRE
Go to component -> Automatic a/c circuit (2 of 2) -> LEFT HIGH SPEED RADIATOR FAN RELAY
Wiring diagram left high speed radiator fan relay (2 of 2)
1 86 LOW SPEED 2 RADIATOR FANS RELAY
A/C PRESSURE SENSOR (ON BOTTOM RIGHT SIDE OF CONDENSER)
BLK WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLU WIRE
BRN/RED WIRE
BRN/YEL WIRE
COOLANT TEMPERATURE SENSOR (ON LEFT END OF CYLINDER HEAD)
ENGINE BAY MAIN FUSE BOX (BEHIND BATTERY)
FUSE 1
FUSE 14
GRN RED/ WIRE
GRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
LEFT HIGH SPEED RADIATOR FAN RELAY
LEFT RADIATOR FAN MOTOR (BEHIND LEFT SIDE OF RADIATOR)
MAIN INSTRUMENT UNIT
RED WIRE
RED/YEL WIRE
RIGHT HIGH SPEED RADIATOR FAN RELAY
RIGHT RADIATOR FAN MOTOR (BEHIND RIGHT SIDE OF RADIATOR)
TRIONIC ENGINE CONTROL MODULE (IN RIGHT REAR OF ENGINE COMPT)
VIO WIRE
VIO/YEL WIRE
WHT WIRE
Go to component -> Cooling fan circuit -> LEFT HIGH SPEED RADIATOR FAN RELAY
