Saab 9-5 I facelift 2 (2005-2010) except jp Wiring diagrams
This page contains all the electrical diagrams for the component. except jp, in which he is found in the car Saab 9-5 I facelift 2 (2005-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
except jp wiring diagram (1 of 3)
A/T
BACK UP LAMP
BLK WIRE
BRN WIRE
DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH)
DICE CONTROL MODULE (ON MAIN RELAY BOX IN DASHBOARD)
EXCEPT JP
FUSE 2
GRN WIRE
GRN/WHT WIRE
HOT IN RUN
INTERIOR REAR VIEW MIRROR
LEFT REVERSING LAMP
M/T
NCA WIRE
REVERSING LIGHT SWITCH
REVERSING LIGHTS SWITCH (ON TRANSMISSION)
RIGHT REVERSING LAMP
TOW BAR CONNECTOR
TRANSMISSION RANGE SWITCH 2 (ON AUTOMATIC TRANSMISSION)
WHT WIRE
WHT/PNK WIRE
Go to component -> Backup lamps circuit, 4 door -> EXCEPT JP
except jp wiring diagram (2 of 3)
130-6 130-3
BLK WIRE
BLK/WHT WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DICE CONTROL MODULE (ON MAIN RELAY BOX IN DASHBOARD)
EXCEPT JP
FUSE 24
FUSE 27
FUSE 35
GRN WIRE
HEAD
HEADLIGHTS SYSTEM
HOT AT ALL TIMES DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) FUSE 20
HOT AT ALL TIMES ENGINE BAY MAXI- FUSES BOX MAXI FUSE 2
HOT IN ACC, ON OR START
HOT IN RUN
HOT IN RUN OR START
LEFT REAR FOG LIGHT
LIGHT SWITCH
MAIN INSTRUMENT UNIT
OFF PARK
OFF PARK 16 4 HEAD
REAR FOG LIGHT
REAR FOGLAMP INDICATOR
REAR FOGLIGHTS SWITCH
RED/GRY WIRE
RED/WHT WIRE
RIGHT REAR FOG LIGHT REAR FOG LIGHT TOW BAR CONNECTOR
VIO/BRN WIRE
WHT WIRE
WHT/PNK WIRE
YEL BRN/ WIRE
YEL/GRY WIRE
Go to component -> Rear fog lamps circuit, 4 door -> EXCEPT JP
except jp wiring diagram (3 of 3)
130-6 130-3
BLK WIRE
BLK/WHT WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DICE CONTROL MODULE (ON MAIN RELAY BOX IN DASHBOARD)
EXCEPT JP
FUSE 24
FUSE 27
FUSE 35
GRN WIRE
GRN/WHT WIRE
HEAD
HEADLIGHTS SYSTEM
HOT AT ALL TIMES DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) FUSE 20
HOT AT ALL TIMES ENGINE BAY MAXI- FUSES BOX MAXI FUSE 2
HOT IN ACC, ON OR START
HOT IN RUN
HOT IN RUN OR START
LEFT REAR FOG LIGHT
LIGHT SWITCH
MAIN INSTRUMENT UNIT
OFF PARK
OFF PARK 16 4 HEAD
REAR FOG LIGHT
REAR FOGLAMP INDICATOR
REAR FOGLIGHTS SWITCH
RED/GRY WIRE
RED/WHT WIRE
RIGHT REAR FOG LIGHT REAR FOG LIGHT
TOW BAR CONNECTOR
VIO/BRN WIRE
WHT WIRE
YEL BRN/ WIRE
YEL/GRY WIRE
Go to component -> Rear fog lamps circuit, 5 door -> EXCEPT JP
