Saab 9-5 I facelift 2 (2005-2010) electrically adjustable driver's seat control Wiring diagram
This page shows the only wiring diagram for the component.electrically adjustable driver's seat control, which is found in the car Saab 9-5 I facelift 2 (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram electrically adjustable driver's seat control (1 of 1)
A/T
AUDIO SYSTEM MAIN UNIT
AUDIO/ NAVIGATION MAIN UNIT
BLK WIRE
BLK/WHT WIRE
BRN/VIO WIRE
BRN/WHT WIRE
CONTROL MODULE
DATA LINK CONNECTOR (UNDER DASH, NEAR STEERING COLUMN)
DICE CONTROL MODULE (ON MAIN RELAY BOX IN DASHBOARD)
ELECTRICALLY ADJUSTABLE DRIVER'S SEAT CONTROL
GRN WIRE
HOT AT ALL TIMES DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) FUSE 9
LEFT RIGHT XENON XENON HEADLAMP HEADLAMP
M/T
MAIN INSTRUMENT UNIT
MODULE (TCM) (A/T) (INSIDE GLOVE BOX)
MODULE (W/ MEMORY) (UNDER DRIVER'S SEAT CUSHION)
PMM CONTROL MODULE (ABOVE GLOVE BOX)
REAR CD CHANGER (AT LEFT REAR OF LUGGAGE COMPT)
RED/GRY WIRE
SAAB PARKING ASSISTANCE (SPA) CONTROL MODULE (LEFT FRONT OF LUGGAGE COMPT)
SATELLITE RADIO RECEIVER (UNDER RIGHT SIDE OF PARCEL SHELF)
SID CONTROL MODULE (ON REAR OF INSTRUMENT CLUSTER)
SRS/AIR BAG CONTROL MODULE (UNDER CENTER CONSOLE, BEHIND HANDBRAKE)
STEERING WHEEL TILT SENSOR
TIRE PRESSURE MONITORING CONTROL MODULE
TRANSMISSION CONTROL
TRIONIC ENGINE CONTROL MODULE (IN RIGHT REAR OF ENGINE COMPT)
TWICE CONTROL MODULE (UNDER DRIVER'S SEAT)
W/ AUTOMATIC HEADLAMP LEVELING
WHT WIRE
WHT/ BLK WIRE
Go to component -> Computer data lines circuit -> ELECTRICALLY ADJUSTABLE DRIVER'S SEAT CONTROL
