Saab 9-5 I facelift 2 (2005-2010) backrest seat heating pad Wiring diagram
This page shows the only wiring diagram for the component.backrest seat heating pad, which is found in the car Saab 9-5 I facelift 2 (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram backrest seat heating pad (1 of 1)
ACC CONTROL MODULE
BACKREST SEAT HEATING PAD
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRY WIRE
BRN/RED WIRE
BRN/VIO WIRE
BRN/WHT WIRE
CUSHION SEAT HEATING PAD
DRIVER SEAT HEATING PAD
ELEC- TRICALLY HEATED REAR SEAT RELAY (IN DASHBOARD MAIN RELAY BOX)
FUSE 10
FUSE 21
GRN/RED WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) FUSE 38
HOT IN RUN OR START
ILLUM
LEFT REAR SEAT HEATING PAD
NCA WIRE
PASSENGER'S SEAT HEATING PAD
REAR SEAT HEATED PAD SWITCH
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT REAR SEAT HEATING PAD
SEAT HEATING PAD TEMPERATURE SENSOR
TWICE CONTROL MODULE (UNDER DRIVER'S SEAT)
VIO BRN/ WIRE
VIO/YEL WIRE
WHT WIRE
WHT/GRY WIRE
YEL WIRE
YEL/GRY WIRE
Go to component -> Heated seats circuit -> BACKREST SEAT HEATING PAD
