Saab 9-5 I facelift 2 (2005-2010) 4 7 16 mobile telephone connector Wiring diagram
This page shows the only wiring diagram for the component.4 7 16 mobile telephone connector, which is found in the car Saab 9-5 I facelift 2 (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 4 7 16 mobile telephone connector (1 of 1)
4 7 16 MOBILE TELEPHONE CONNECTOR
AUDIO SYSTEM MAIN UNIT
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH)
FUSE 13
FUSE 9
GRN WIRE
GRY WIRE
GRY/BLK WIRE
HORNS SYSTEM
HOT AT ALL TIMES
NCA WIRE
ONSTAR
ORG/ WIRE
PRESET
RED/BLU WIRE
RED/GRY WIRE
SATELLITE RADIO ANTENNA
SATELLITE RADIO RECEIVER (UNDER RIGHT SIDE OF PARCEL SHELF)
SEEK SEEK DOWN FWD
SEEK SEEK UP BACK
SELECT
SID CONTROL MODULE (ON REAR OF INSTRUMENT CLUSTER)
STARTING/ CHARGING SYSTEM
STEERING WHEEL HORN/SWITCHES CONTACT UNIT (IN STEERING WHEEL, UNDER CRASH PAD)
STEERING WHEEL SWITCH UNIT
TELCO
VIO/WHT WIRE
VOL DOWN
VOL UP
WHT WIRE
YEL WIRE
YEL/VIO WIRE
Go to component -> Premium radio circuit, without navigation (1 of 2) -> 4 7 16 MOBILE TELEPHONE CONNECTOR
