Saab 9-5 I (1997-2001) winter switch Wiring diagrams

1/2- 3/4 SHIFT SOL. 2/3 SHIFT SOL. TCC SOL BLK WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRAKE LIGHT SWITCH (ON PEDAL BRACKET) BRN WIRE CHECK GEAR BOX IND DATA LINK CONNECTOR (UNDER DASH, NEAR STEERING COLUMN) DICE CONTROL MODULE (ABOVE INTERIOR RELAY BLOCK) FUSE FUSE 12 FUSE 27 FUSE 29 GRN WIRE GRN/RED WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START INPUT SHAFT SPEED SENSOR INTERIOR FUSE BLOCK (BEHIND LEFT END OF DASH) INTERIOR LIGHT SYSTEM MAIN INSTRUMENT DISPLAY NCA WIRE ORG/WHT WIRE OUTPUT SHAFT SPEED SENSOR PNK WIRE PNK/WHT WIRE PRESSURE CONTROL SOLENOID RED WIRE SOLID STATE SPORT IND SPORT SWITCH TCM SOLENOID VALVES TRANSMISSION CONTROL MODULE (ON RIGHT SIDE OF FIREWALL) TRANSMISSION FLUID TEMPERATURE SENSOR (UNDER GEAR- BOX) VIO WIRE WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/YEL WIRE WINTER IND WINTER SWITCH YEL WIRE

ANTI-LOCK BRAKES SYSTEM BLK WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE DICE CONTROL MODULE (ABOVE INTERIOR RELAY BLOCK) ELECTRIC WINDOW LIFT SWITCH ELECTRICALLY HEATED REAR SEAT SWITCH EXTRA FOGLIGHTS SWITCH FRONT ASHTRAY, CIGARETTE LIGHTER LAMP FUSE 8 GRN WIRE HAZARD FLASHER SWITCH HEATING VENTILATION CONTROL PANEL HOT AT ALL TIMES INSTRUMENT LIGHTING RHEOATAT INTERIOR FUSE BLOCK (BEHIND LEFT END OF DASH) LEFT SEAT HEATING PAD SWITCH LEFT SEAT VENTILATION SWITCH LIGHT SWITCH MOBILE TELEPHONE CONNECTOR PNK WIRE RADIO CONNECTOR SWITCH A REAR ASHTRAY, CIGARETTE LIGHTER LAMP RED WIRE RED/WHT WIRE RIGHT SEAT HEATING PAD SWITCH RIGHT SEAT VENTILATION SWITCH SELECTING LEVEL INDICATOR LIGHTING LAMP SID (IN CENTER OF DASH) SIMULTANEOUS CENTRAL LOCKING SWITCH TCS OFF SWITCH TRANSMISSIONS SYSTEM WHT WIRE WINTER SWITCH
