Saab 9-5 I (1997-2001) spark plug connectors Wiring diagrams

BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BRN WIRE BLU/RED WIRE BRN/BLU WIRE CHARGE AIR PRESSURE SENSOR (LEFT PIPE CONNECTION OF CHARGE AIR COOLER) ENGINE COOLANT TEMPERATURE SENSOR (ON LEFT SIDE OF CYLINDER HEAD) EVAP PRESSURE SENSOR (1999) (NEAR FUEL TANK FILLER HOSE) FUEL PUMP MOTOR (IN FUEL TANK) FUEL PUMP RELAY (ON INTERIOR RELAY BLOCK) FUSE 15 FUSE 19 GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRY WIRE GRY/RED WIRE HEATED OXYGEN SENSOR 1 (UPSTREAM OF CATALYTIC CONVERTER) HEATED OXYGEN SENSOR 2 (1999) (DOWNSTREAM OF CATALYTIC CONVERTER) IGNITION DISCHARGE MODULE (ON CAMSHAFT COVER) INTAKE AIR TEMPERATURE SENSOR (ON INTAKE MANIFOLD) INTERIOR FUSE BLOCK (BEHIND LEFT END OF DASH) MASS AIRFLOW SENSOR (BEHIND RIGHT HEADLAMP) ORG/ WIRE ORG/WHT WIRE PNK/WHT WIRE RED WIRE RED/BLU WIRE RED/WHT WIRE SPARK PLUG CONNECTORS VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/GRN WIRE YEL WIRE YEL/BLU WIRE YEL/GRY WIRE YEL/RED WIRE

BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/GRN WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE CHARGE AIR PRESSURE SENSOR (ON HOSE BETWEEN CHARGE AIR COOLER AND THROTTLE BODY) ENGINE COOLANT TEMPERATURE SENSOR (ON INTAKE MANIFOLD FLANGE) EVAP PRESSURE SENSOR (NEAR FUEL TANK FILLER HOSE) FUEL PUMP MOTOR (IN FUEL TANK) FUEL PUMP RELAY (ON INTERIOR RELAY BLOCK) FUSE 15 FUSE 19 GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRY WIRE GRY/RED WIRE HEATED OXYGEN SENSOR 1 (UPSTREAM OF CATALYTIC CONVERTER) HEATED OXYGEN SENSOR 2 (DOWNSTREAM OF CATALYTIC CONVERTER) IGNITION DISCHARGE MODULE (CYLINDER BANK 1) (ON CYLINDER BANK 1 CAMSHAFT COVER) INTAKE AIR TEMPERATURE SENSOR (ON INTAKE MANIFOLD) INTERIOR FUSE BLOCK (BEHIND LEFT END OF DASH) MASS AIRFLOW SENSOR (BEHIND RIGHT HEADLAMP) ORG/ WIRE ORG/WHT WIRE PNK/WHT WIRE RED WIRE RED/BLU WIRE RED/WHT WIRE SPARK PLUG CONNECTORS VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/GRN WIRE YEL WIRE YEL/BLU WIRE YEL/GRY WIRE YEL/RED WIRE
