Saab 9-5 I (1997-2001) right rear shelf speaker Wiring diagram
This page shows the only wiring diagram for the component.right rear shelf speaker, which is found in the car Saab 9-5 I (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear shelf speaker (1 of 1)
5 8 7 MOBILE TELEPHONE CONNECTOR (BY RADIO CONSOLE)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
CD CHANGER
CENTER DASH SPEAKER
CLOCK- SPRING
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DRIVER'S DOOR SPEAKER
FUSE
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRY WIRE
GRY/WHT WIRE
HORN SWITCH
HOT AT ALL TIMES FUSE 9
HOT IN RUN, START OR ACC
INTERIOR FUSE BLOCK (BEHIND LEFT END OF DASH) FUSE 13
LEFT DASH SPEAKER
LEFT REAR DOOR SPEAKER
LEFT REAR SHELF SPEAKER
NCA WIRE
NXT
ORG/ WIRE
ORG/WHT WIRE
PASSEN- GER'S DOOR SPEAKER
PRESTIGE ONLY
RADIO (CENTER OF DASH)
RADIO AMPLIFIER (BELOW RIGHT "A" PILLAR)
RADIO ANTENNA AMPLIFIER (ON RIGHT "C" PILLAR)
RED WIRE
RED/WHT WIRE
RIGHT DASH SPEAKER
RIGHT REAR DOOR SPEAKER
RIGHT REAR SHELF SPEAKER
SID (CENTER OF DASH)
SRC
STEERING WHEEL SWITCH UNIT (W/ STEERING CONTROL RADIO ONLY)
WHT WIRE
YEL WIRE
YEL/WHT WIRE
