Saab 9-5 I (1997-2001) left main lamp/ dipped beam lamp Wiring diagram
This page shows the only wiring diagram for the component.left main lamp/ dipped beam lamp, which is found in the car Saab 9-5 I (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left main lamp/ dipped beam lamp (1 of 1)
BATTERY
BLK WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
DICE CONTROL MODULE (ABOVE INTERIOR RELAY BLOCK)
DIP SWITCH
DIPPED BEAM RELAY (UNDER- HOOD FUSE/ RELAY BLOCK)
FOGLIGHTS RELAY (IN UNDERHOOD FUSE/RELAY BLOCK)
FRONT LAMPS FILAMENT MONITOR (IN UNDERHOOD FUSE/RELAY BLOCK)
FUSE 13
FUSE 17
FUSE 35 FUSE 20 FUSE 31
FUSE 7 FUSE 8
FUSE 9 FUSE 10
GRN WIRE
GRN/GRY WIRE
GRN/RED WIRE
GRY WIRE
HEAD
HEADLAMPS SYSTEM (FOGLIGHTS CIRCUIT)
HOT AT ALL TIMES
HOT AT ALL TIMES UNDERHOOD MAXI FUSE BLOCK (NEXT TO BATTERY) MAXI FUSE 2
HOT IN HOT IN
IGNITION SWITCH
ILLUM EXTRA FOG- LIGHTS SWITCH
INTERIOR FUSE BLOCK (BEHIND LEFT END OF DASH) FUSE 3
INTERIOR LIGHTS
INTERIOR LIGHTS (RHEOSTAT)
LEFT FOG LAMP
LEFT FRONT FOG/ CORNERING LAMP ASSEMBLY
LEFT HEADLAMP/ PARKING LAMP ASSEMBLY LEFT FRONT PARKING LAMP
LEFT MAIN LAMP/ DIPPED BEAM LAMP
LIGHT SWITCH
LIGHTS ON IND
LOCK
MAIN BEAM IND
MAIN BEAM RELAY (UNDER- HOOD FUSE/ RELAY BLOCK)
MAIN INSTRUMENT DISPLAY
OFF PARK
ORG/WHT WIRE
PNK OFF PARK HEAD WIRE
PNK WIRE
REAR FOGLIGHTS SWITCH
RED WIRE
RIGHT FRONT FOG/ CORNERING LAMP ASSEMBLY RIGHT FOG LAMP
RIGHT HEADLAMP/ PARKING LAMP ASSEMBLY RIGHT FRONT PARKING LAMP
RIGHT MAIN LAMP/ DIPPED BEAM LAMP
RUN WIRE
SAAB INFORMATION DISPLAY (SID) (CENTER OF DASH)
UNDERHOOD FUSE/RELAY BLOCK (LEFT REAR CORNER OF ENG COMPT)
VIO WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Headlamps & front fog lamps circuit -> LEFT MAIN LAMP/ DIPPED BEAM LAMP
