Saab 9-5 I (1997-2001) high- level brake lamp Wiring diagram

A/T BLK WIRE BLK/RED WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRAKE LAMP FUSE 27 GRN WIRE GRN/RED WIRE GRY/RED WIRE HEAD HEADLAMPS SYSTEM (FOG LIGHTS CIRCUIT) HEADLIGHTS SYSTEM HIGH- LEVEL BRAKE LAMP HOT AT ALL TIMES HOT IN HOT IN RUN, START OR ACC IGNITION SWITCH INTERIOR FUSE BLOCK (BEHIND LEFT END OF DASH) FUSE 35 INTERIOR LIGHTS LEFT FRONT FOG/ CORNERING LAMP ASSEMBLY LEFT CORNERING LAMP LEFT REAR LIGHT CLUSTER LEFT SIDE DIREC- TION INDI- CATOR LAMP RIGHT SIDE DIREC- TION INDI- CATOR LAMP LEFT TURN IND LIGHT SWITCH LIGHTS ON IND LOCK M/T MAIN INSTRUMENT DISPLAY OFF PARK PNK OFF PARK HEAD WIRE PNK WIRE REAR FOG LAMPS SWITCH REAR PARK- ING LAMP DIRECTION INDICATOR LAMP RED WIRE RED/BLK WIRE REVERSING LIGHT RELAY (ON INTERIOR RELAY BLOCK) RIGHT FRONT FOG/ CORNERING LAMP ASSEMBLY RIGHT CORNERING LAMP RIGHT REAR LIGHT CLUSTER RIGHT TURN IND RUN WIRE UNDERHOOD FUSE/RELAY BLOCK (LEFT REAR CORNER OF ENG COMPT) MAXI FUSE 2 VIO WIRE WHT WIRE YEL WIRE YEL/GRY WIRE YEL/RED WIRE YEL/WHT WIRE
