Saab 9-5 I (1997-2001) electrically adjustable driver's seat with memory switch Wiring diagram
This page shows the only wiring diagram for the component.electrically adjustable driver's seat with memory switch, which is found in the car Saab 9-5 I (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram electrically adjustable driver's seat with memory switch (1 of 1)
1 2 3 4 (PIN 5-17 NOT USED) 18 19 20 21 22 23 24 25 26
BACKWARD
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DOWN
DRIVER'S MEMORY SEAT CONTROL MODULE (UNDER DRIVER'S SEAT CUSHION)
DRIVER'S SEAT BACKREST ADJUSTMENT POSITION SENSOR/MOTOR
DRIVER'S SEAT FORE-AND-AFT ADJUSTMENT POSITION SENSOR/MOTOR
DRIVER'S SEAT FRONT HEIGHT ADJUSTMENT POSITION SENSOR/MOTOR
DRIVER'S SEAT REAR HEIGHT ADJUSTMENT POSITION SENSOR/MOTOR
ELECTRICALLY ADJUSTABLE DRIVER'S SEAT SWITCH
ELECTRICALLY ADJUSTABLE DRIVER'S SEAT WITH MEMORY SWITCH
FORWARD/
FUSE 25
FUSE 27
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BRN WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
INTERIOR FUSE BLOCK (BEHIND LEFT END OF DASH)
LAYBACK
MOTOR
ORG/ WIRE
POSITION SENSOR
REAR
RED WIRE
RED/BLU WIRE
UP FRONT
UPRIGHT
WHT WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Memory seat circuit -> ELECTRICALLY ADJUSTABLE DRIVER'S SEAT WITH MEMORY SWITCH
