Saab 9-5 I (1997-2001) central locking boot lid motor Wiring diagram
This page shows the only wiring diagram for the component.central locking boot lid motor, which is found in the car Saab 9-5 I (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram central locking boot lid motor (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BOOT LID SWITCH
CENTRAL LOCKING BOOT LID MOTOR
FUSE 11
GRN/GRY WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
INTERIOR FUSE BLOCK (BEHIND LEFT END OF DASH)
LUGGAGE COMPARTMENT LIGHTING SWITCH (IN BOOT LID LOCK)
LUGGAGE COMPARTMENT LOCK MICROSWITCH (IN BOOT LID LOCK)
RED WIRE
TWICE CONTROL MODULE (UNDER DRIVER'S SEAT)
YEL WIRE
Go to component -> Trunk release circuit -> CENTRAL LOCKING BOOT LID MOTOR
