Saab 9-5 I (1997-2001) backrest rate adjust motor Wiring diagram
This page shows the only wiring diagram for the component.backrest rate adjust motor, which is found in the car Saab 9-5 I (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram backrest rate adjust motor (1 of 1)
BACKREST RATE ADJUST MOTOR
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
ELECTRICALLY ADJUSTABLE PASSENGER'S SEAT RELAY (UNDER PAS- SENGER'S SEAT)
ELECTRICALLY ADJUSTABLE PASSENGER'S SEAT SWITCH
FORE- AND-AFT ADJUST MOTOR
FRONT HEIGHT ADJUST MOTOR
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES FUSE 11
INTERIOR FUSE BLOCK (BEHIND LEFT END OF DASH)
NCA WIRE
REAR HEIGHT ADJUST MOTOR
RED WIRE
TWICE CONTROL MODULE (UNDER DRIVER'S SEAT)
UP DOWN
YEL WIRE
YEL/WHT WIRE
Go to component -> Passenger seat circuit -> BACKREST RATE ADJUST MOTOR
