Saab 9-5 I (1997-2001) 2-speed radiator fan high speed relay Wiring diagrams
This page contains all the electrical diagrams for the component. 2-speed radiator fan high speed relay, in which he is found in the car Saab 9-5 I (1997-2001). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 2-speed radiator fan high speed relay (1 of 2)
2-SPEED RADIATOR FAN HIGH SPEED RELAY
2-SPEED RADIATOR FAN HIGH SPEED RELAY (W/ DUAL FANS)
2-SPEED RADIATOR FAN LOW SPEED RELAY
A/C PRESSURE SENSOR (ON BOTTOM RIGHT SIDE OF EVAPORATOR)
BLK WIRE
BLU/GRN WIRE
BLU/YEL WIRE
BRN/WHT WIRE
FUSE 15
FUSE 6
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/RED WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
LEFT RADIATOR FAN MOTOR
MAIN INSTRUMENT DISPLAY
ORG/ WIRE
RED WIRE
RED/WHT WIRE
RIGHT RADIATOR FAN MOTOR
TRIONIC CONTROL MODULE (OBDII) (BEHIND RIGHT KICK PANEL)
UNDERHOOD FUSE/RELAY BLOCK (LEFT REAR CORNER OF ENG COMPT)
WHT GRN/ WIRE
WHT WIRE
WHT/GRN WIRE
Go to component -> Dual speed cooling fan circuit -> 2-SPEED RADIATOR FAN HIGH SPEED RELAY
Wiring diagram 2-speed radiator fan high speed relay (2 of 2)
2-SPEED RADIATOR
2-SPEED RADIATOR FAN HIGH SPEED RELAY
2-SPEED RADIATOR FAN LOW SPEED RELAY
BLK WIRE
BRN/WHT WIRE
ENGINE BAY MAIN RELAY BOARD (BEHIND BATTERY)
FAN RESISTOR (ON RADIATOR FAN SHROUD)
FUSE 15
GRN WIRE
GRN/RED WIRE
GRY/RED WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
MAIN INSTRUMENT DISPLAY
NCA WIRE
RADIATOR FAN MOTOR
RED WIRE
RED/WHT WIRE
TRIONIC CONTROL MODULE (OBDII) (BEHIND RIGHT KICK PANEL)
UNDERHOOD FUSE/RELAY BLOCK (LEFT REAR CORNER OF ENG COMPT)
WHT WIRE
WHT/GRN WIRE
Go to component -> Single speed cooling fan circuit -> 2-SPEED RADIATOR FAN HIGH SPEED RELAY
