Electronic power steering circuit for Saab 9-4X I (2011-2011)
Electronic power steering circuit
1 16 BATT GND
6105 6106 5986 6641 1295 2500 2500 2501 2501 2087 COMPUTER DATA LINES SYSTEM
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLK/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DRIVER INFORMATION CENTER (DIC) DISPLAY INSTRUMENT CLUSTER
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
FUSE 24
HOT AT ALL TIMES
LOW GMLAN SERIAL DATA LOGIC
LT BLU WIRE
LT BLU/BLK WIRE
RED/BLK WIRE
SERIAL SERIAL GND DATA- DATA+
STEERING WHEEL ANGLE SENSOR
SUPPLY VOLTAGE
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK
VARIABLE POWER STEERING SOLENOID VALVE
YEL WIRE
