Saab 9-4X I (2011-2011) w/o parking assist, w/ rearview camera Wiring diagram
This page shows the only wiring diagram for the component.w/o parking assist, w/ rearview camera, which is found in the car Saab 9-4X I (2011-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o parking assist, w/ rearview camera (1 of 1)
BLK WIRE
CHILD SECURITY LOCK DISABLE RELAY
FRONT, REAR PARKING ASSIST CONTROL MODULE
FUEL DOOR UNLATCH RELAY
LEFT REAR DOOR COURTESY LAMP
LEFT REAR LEFT REAR DOOR WINDOW LATCH SWITCH ASSEMBLY
LIFTGATE UNLATCH RELAY
NCA WIRE
PASSENGER DOOR COURTESY LAMP
PASSENGER DOOR LATCH ASSEMBLY
PASSENGER OUTSIDE REARVIEW MIRROR
PASSENGER PRESENCE DETECTION MODULE
PASSENGER SEAT ADJUSTER SWITCH
PASSENGER SEAT LUMBAR SUPPORT SWITCH
PASSENGER WINDOW MOTOR
PASSENGER WINDOW SWITCH
REAR BODY FUSE BLOCK
REAR DEFOGGER RELAY
REAR VIEW CAMERA
REAR WIPER RELAY
RIGHT TURN SIGNAL REPEATER LAMP
W/ MANUAL FOLDING
W/ PARKING ASSIST, REARVIEW CAMERA
W/ PARKING ASSIST, W/O REARVIEW CAMERA
W/O MANUAL FOLDING
W/O PARKING ASSIST, W/ REARVIEW CAMERA
WHT WIRE
Go to component -> Ground distribution circuit (4 of 5) -> W/O PARKING ASSIST, W/ REARVIEW CAMERA
