Saab 9-4X I (2011-2011) w/o memory driver seat/ memory driver convenience package Wiring diagram
This page shows the only wiring diagram for the component.w/o memory driver seat/ memory driver convenience package, which is found in the car Saab 9-4X I (2011-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o memory driver seat/ memory driver convenience package (1 of 1)
BLK WIRE
DK GRN WIRE
DVR SEAT VENT MTR CTRL
DVR SEAT VENT MTR CTRL 1
FUSE
HOT W/ IGNITION MAIN RELAY ENERGIZED
LOGIC
LOGIC DRIVER BACK SEAT BLOWER MOTOR
LOGIC DRIVER CUSHION SEAT BLOWER MOTOR
PASSENGER BACK SEAT BLOWER MOTOR
PASSENGER CUSHION SEAT BLOWER MOTOR
PNK WIRE
REAR BODY FUSE BLOCK
RUN/CNK IGN 1 VOLT
SEAT HEATING CONTROL MODUL
SEAT MEMORY CONTROL MODUL
VENT MTR CTRL DVR SEAT
VENT MTR CTRL PASS SEAT
W/ MEMORY DRIVER SEAT/ MEMORY DRIVER CONVENIENCE PACKAGE
W/O MEMORY DRIVER SEAT/ MEMORY DRIVER CONVENIENCE PACKAGE
WHT WIRE
Go to component -> Seat ventilation circuit -> W/O MEMORY DRIVER SEAT/ MEMORY DRIVER CONVENIENCE PACKAGE
