Saab 9-4X I (2011-2011) w/o continuously variable damping, except awd Wiring diagram
This page shows the only wiring diagram for the component.w/o continuously variable damping, except awd, which is found in the car Saab 9-4X I (2011-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o continuously variable damping, except awd (1 of 1)
AWD W/O CONTINUOUSLY VARIABLE DAMPING
DK BLU WIRE
DK GRN WIRE
ELECTRONIC BRAKE CONTROL MODULE
EXCEPT AWD
FUEL PUMP CONTROL MODULE
HEADLAMP LEVELING CONTROL MODULE (IF EQUIPPED)
HI SPD GMLAN SERIAL DATA + HI SPD GMLAN SERIAL DATA -
LT BLU WIRE
PARKING BRAKE CONTROL MODULE
REAR DIFFERENTIAL CLUTCH CONTROL MODULE (AWD)
SERIAL DATA COMM ENABLE
SUSPENSION CONTROL MODULE (W/ CONTINUOUSLY VARIABLE DAMPING)
TAN WIRE
TAN/BLK WIRE
TAN/LT GRN WIRE
TAN/YEL WIRE
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE
W/ CONTINUOUSLY VARIABLE DAMPING
W/ CONTINUOUSLY VARIABLE DAMPING, AWD
W/ CONTINUOUSLY W/O CONTINUOUSLY VARIABLE DAMPING VARIABLE DAMPING
W/ HID
W/ ONSTAR
W/O CONTINUOUSLY VARIABLE DAMPING
W/O CONTINUOUSLY VARIABLE DAMPING, EXCEPT AWD
W/O HID
W/O ONSTAR
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Computer data lines circuit (3 of 4) -> W/O CONTINUOUSLY VARIABLE DAMPING, EXCEPT AWD
