Saab 9-4X I (2011-2011) w/ power liftgate premium audio sound system Wiring diagram
This page shows the only wiring diagram for the component.w/ power liftgate premium audio sound system, which is found in the car Saab 9-4X I (2011-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ power liftgate premium audio sound system (1 of 1)
ACCESSORY POWER RECEPTACLE REAR COMPARTMENT
BLK WIRE
CENTER TAIL LAMP
DOME LAMP SWITCH
DOME OVER- OVER- HEAD HEAD CONSOLE CONSOLE ACCENT READING LAMP LAMPS
HIGH MOUNTED CENTER STOP LAMP
INSIDE REAR VIEW MIRROR
KEYLESS ENTRY CONTROL MODULE
LEFT
LEFT BACKUP LAMP
LEFT CARGO LAMP
LEFT LICENSE PLATE LAMP
LEFT REAR DOME/ READING LAMPS
LEFT REAR SIDE MARKER LAMP
LEFT REAR TURN SIGNAL LAMP
LEFT STOP LAMP
LEFT TAIL LAMP ASSEMBLY
LIFTGATE HANDLE SWITCH
NCA WIRE
PARKING BRAKE CONTROL MODULE
PASSENGER AIR BAG DISABLE INDICATOR
REAR BODY FUSE- REAR BLOCK WIPER RELAY
REAR DEFOGGER GRID
REAR WIPER MOTOR
RIGHT BACKUP LAMP
RIGHT LICENSE PLATE LAMP
RIGHT REAR DOME/ READING LAMPS
W/ POWER LIFTGATE PREMIUM AUDIO SOUND SYSTEM
W/ REAR VIEW CAMERA
W/O REAR VIEW CAMERA
WHT WIRE
Go to component -> Ground distribution circuit (5 of 5) -> W/ POWER LIFTGATE PREMIUM AUDIO SOUND SYSTEM
