Saab 9-4X I (2011-2011) trans- mission shift lever position indicator wiring diagram
This page shows the only wiring diagram for the component.trans- mission shift lever position indicator, which is found in the car Saab 9-4X I (2011-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
trans- mission shift lever position indicator wiring diagram (1 of 1)
2.8L
3.0L
ACCESSORY RELAY
AIR TEMPERATURE MASS AIR FLOW/ INTAKE SENSOR
BLK WIRE
BLOWER MOTOR CONTROL MODULE
COOLING FAN RELAY
ENGINE CONTROL MODULE
HVAC CONTROL MODULE
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE
INSTRUMENT PANEL FUSE BLOCK
INSTRUMENT PANEL INSTRUMENT ACCESSORY PANEL POWER COMPARTMENT RECEPTACLE LAMP
LEFT COOLING COOLING FAN FAN DIODE DIODE
MASS AIR FLOW SENSOR
MULTI- FUNCTION CENTER CONSOLE SWITCH
NCA WIRE
PARK BRAKE CONTROL SWITCH
RADIO
RIGHT CARGO LAMP
RIGHT COOLING FAN DIODE
RIGHT REAR SIDE MARKER LAMP
RIGHT REAR TURN SIGNAL LAMP
RIGHT STOP LAMP
RIGHT TAIL LAMP ASSEMBLY
SPORT MODE SWITCH
TRANS- MISSION SHIFT LEVER
TRANS- MISSION SHIFT LEVER POSITION INDICATOR
TRANSMISSION CONTROL MODULE
UNDERHOOD FUSE BLOCK
WHT WIRE
Go to component -> Ground distribution circuit (2 of 5) -> TRANS- MISSION SHIFT LEVER POSITION INDICATOR
