Saab 9-4X I (2011-2011) tap up/tap down sw sig ppl Wiring diagrams
This page contains all the electrical diagrams for the component. tap up/tap down sw sig ppl, in which he is found in the car Saab 9-4X I (2011-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
tap up/tap down sw sig ppl wiring diagram (1 of 2)
AUTOMATIC TRANSMISSION ASSEMBLY
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM)
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DRIVER INFORMATION CENTER DISPLAY
ENGINE CONTROL MODULE (ECM)
FUSE 19
FUSE 2
GEAR SHIFT POSITION SENSOR
HI SPD GMLAN SER DATA (+) SIG GND
HI SPD GMLAN SER DATA -
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
IGN VOLT IGN VOLTAGE
IGNITION CYLINDER LOCK CONTROL SWITCH
INSTRUMENT CLUSTER
KEY CAP/CLMN LOCK SH POS SIG TAP UP/TAP DOWN SW SIG
LEFT TRANSMISSION MANUAL SHIFT SWITCH
LINE PRESSURE CONTROL SOLENOID VALUE
LOGIC
LOGIC LOW SPD GMLAN SER DATA
LOW SPD GMLAN SER DATA
NCA WIRE
ORG/BLK WIRE
PNK 2 3 WIRE
PNK WIRE
PPL
PPL/WHT WIRE
PRESSURE CONTROL SOLENOID VALUE 1
PRESSURE CONTROL SOLENOID VALUE 2
PRESSURE CONTROL SOLENOID VALUE 3
PRESSURE CONTROL SOLENOID VALUE 4
RED/WHT WIRE
RIGHT TRANSMISSION MANUAL SHIFT SWITCH
SHIFT SOLENOID VALUE 1
SHIFT SOLENOID VALUE 2
STEERING WHEEL AIR BAG COIL
SYSTEM
TAN WIRE
TAN/BLK WIRE
TAP UP/TAP DOWN SW SIG PPL
TORQUE CONVERTER CLUTCH PRESSURE CONTROL SOLENOID VALUE
TRANS PARK/ NEUTRAL SIG HI SPD GMLAN SER DATA (-)
TRANSMISSION CONTROL MODULE
TRANSMISSION FLUID TEMPERATURE SENSOR
TRANSMISSION INPUT SHAFT SPEED SENSOR (ISS)
TRANSMISSION MANUAL SHIFT SWITCH
TRANSMISSION OUTPUT SHAFT SPEED SENSOR (OSS)
TRANSMISSION PARK/ NEUTRAL SIG
TRANSMISSION SHIFT LEVER
UNDERHOOD FUSE BLOCK
Go to component -> 2.8l turbo, a/t circuit -> TAP UP/TAP DOWN SW SIG PPL
tap up/tap down sw sig ppl wiring diagram (2 of 2)
AUTOMATIC TRANSMISSION ASSEMBLY
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM)
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID
DK BLU WIRE
DK GRN WIRE
DRIVER INFORMATION CENTER DISPLAY
ENGINE CONTROL MODULE (ECM)
FUSE
HI SPD GMLAN SER DATA -
HOT AT ALL TIMES UNDERHOOD FUSE BLOCK FUSE
HOT W/ IGNITION MAIN RELAY ENERGIZED
IGN
IGNITION CYLINDER LOCK CONTROL SWITCH
INSTRUMENT CLUSTER
ISS ISS HIGH LOW
KEY CAP/CLMN LOCK SH POS SIG
LEFT TRANSMISSION MANUAL SHIFT SWITCH
LOGIC LOW SPD GMLAN SER DATA
LOW REF
LOW SPD GMLAN SER DATA
NCA WIRE
ORG/BLK WIRE
OSS OSS HIGH LOW
PC 1 SOLENOID
PC 2 SOLENOID
PC 3 SOLENOID
PC 4 SOLENOID
PC 5 SOLENOID
PNK 2 3 WIRE
PNK WIRE
PPL
PPL/WHT WIRE
PRESSURE CONTROL SOLENOID VALVE 1
PRESSURE CONTROL SOLENOID VALVE 2
PRESSURE CONTROL SOLENOID VALVE 3
PRESSURE CONTROL SOLENOID VALVE 4
PRESSURE CONTROL SOLENOID VALVE 5
RED/WHT WIRE
RIGHT TRANSMISSION MANUAL SHIFT SWITCH
SHIFT SOLENOID VALVE 1
SHIFT SOLENOID VALVE 2
SIG GND
SS 1
SS 2
STEERING WHEEL AIR BAG COIL
SYSTEM
TAN WIRE
TAN/BLK WIRE
TAP UP/TAP DOWN SW SIG PPL
TCC SOLENOID
TFP 1
TFP 3
TFP 4
TFP 5
TFT
TORQUE CONVERTER CLUTCH PRESSURE CONTROL SOLENOID VALVE
TRANS PARK NEUTRAL SIG
TRANSMISSION CONTROL MODULE
TRANSMISSION FLUID PRESSURE SWITCH
TRANSMISSION FLUID TEMPERATURE SENSOR
TRANSMISSION INPUT SHAFT SPEED SENSOR
TRANSMISSION MANUAL SHIFT SWITCH
TRANSMISSION OUTPUT SHAFT SPEED SENSOR
TRANSMISSION PARK/ NEUTRAL SIG HI SPD GMLAN SER DATA (+)
TRANSMISSION SHIFT LEVER
VALVE ASSEMBLY
WHT WIRE
Go to component -> 3.0l, a/t circuit -> TAP UP/TAP DOWN SW SIG PPL
