Saab 9-4X I (2011-2011) sunroof sunshade Wiring diagram
This page shows the only wiring diagram for the component.sunroof sunshade, which is found in the car Saab 9-4X I (2011-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sunroof sunshade (1 of 1)
BLK WIRE
BRN WIRE
CMFRT
DIMMER SW
DK BLU WIRE
DK GRN WIRE
DOME LAMP SWITCH
FRONT FOG LP SW
GRY WIRE
HEADLAMP SWITCH
HORN SWITCH
INSTRUMENT PANEL MULTIFUNCTION SWITCH
INTEL
LEFT WHEEL STEERING CONTROLS SWITCH
LIFT GATE INTERIOR CONTROL SWITCH (W/ POWER LIFTGATE)
LOGIC GARAGE DOOR OPENER (IF EQUIPPED)
OUTSIDE REARVIEW MIRROR SWITCH
PASSENGER WINDOW SWITCH
PNK WIRE
PPL/WHT WIRE
RIGHT WHEEL STEERING CONTROLS SWITCH
SOUND, CRUISE CONTROL SYSTEMS
SPORT MODE SWITCH SPRT
STEERING WHEEL AIR BAG COIL
SUNROOF SUNSHADE
SUNROOF SWITCH (IF EQUIPPED)
SWITCH (IF EQUIPPED)
UNDER- HOOD FUSE FUSE BLOCK
W/ SUNROOF, UNIVERSAL GARAGE DOOR OPENER
W/O SUNROOF, UNIVERSAL GARAGE DOOR OPENER
WHT WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (2 of 2) -> SUNROOF SUNSHADE
