Saab 9-4X I (2011-2011) sport mode switch Wiring diagrams
This page contains all the electrical diagrams for the component. sport mode switch, in which he is found in the car Saab 9-4X I (2011-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram sport mode switch (1 of 3)
1 4 5 6 HI SPD GMLAN - HI SPD GMLAN + SENS SPLY VOLT SIG GND
2.8L
3.0L
3.0L 2.8L
5 VOLT REF LOW REF
ABS IND.
AUXILIARY BRAKE BOOSTER PUMP
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM)
BRAKE BOOSTER PUMP MOTOR RELAY
BRAKE BOOSTER VACUUM SENSOR
BRAKE FLUID LEVEL SWITCH
BRAKE IND
BRAKE PRESSURE MODULATOR VALVE (BPMV)
BRN WIRE
COMBINED VEH INTERIAL SENS SPLY VOLT
COMPUTER 2500 2500 2501 2501 6641 1050 2501 DATA LINES SYSTEM
COMPUTER DATA LINES LINES
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
ENGINE CONTROL MODULE
ETC BRAKE SIG
FUSE 12
FUSE 24
FUSE 35
GRY WIRE
HI SPD GMLAN
HI SPD GMLAN SERIAL DATA
HOT AT ALL TIMES
HOT AT ALL TIMES UNDERHOOD FUSE BLOCK
INSTRUMENT CLUSTER
LEFT FRONT WHEEL SPEED SENSOR (WSS)
LEFT REAR WHEEL SPEED SENSOR (WSS)
LF AAS WHEEL SPD SENS SIG
LOGIC
LOW REF
LT BLU WIRE
LT BLU/BLK WIRE
LT BLU/WHT WIRE
LT GRN WIRE
MULTI-AXIS ACCELEROMETER SENSOR
ORG/ WIRE
PPL
PPL BRAKE FLUID LEVEL SENE SIG
PUMP MOTOR CONTROL
RADIO
RED/BLK WIRE
RIGHT FRONT WHEEL SPEED SENSOR (WSS)
RIGHT REAR WHEEL SPEED SENSOR (WSS)
SENS SIG BRK APLY
SERIAL DATA (-) HI SPD GMLAN
SERIAL DATA COMMUNICATION ENABLE
SPD GMLAN
SPLY VOLT BRK APLY SENS
SPORT MODE SWITCH
STEERING WHEEL ANGLE SENSOR
TAN WIRE
TAN/BLK WIRE
TRACTION CONTROL IND
TRACTION CONTROL SWITCH
TRACTION CTRL SW SIG
TRACTION OFF IND
VARIABLE POWER STEERING SOLENOID VALVE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Anti-lock brakes circuit -> SPORT MODE SWITCH
Wiring diagram sport mode switch (2 of 3)
2.8L
3.0L
ACCESSORY RELAY
AIR TEMPERATURE MASS AIR FLOW/ INTAKE SENSOR
BLK WIRE
BLOWER MOTOR CONTROL MODULE
COOLING FAN RELAY
ENGINE CONTROL MODULE
HVAC CONTROL MODULE
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE
INSTRUMENT PANEL FUSE BLOCK
INSTRUMENT PANEL INSTRUMENT ACCESSORY PANEL POWER COMPARTMENT RECEPTACLE LAMP
LEFT COOLING COOLING FAN FAN DIODE DIODE
MASS AIR FLOW SENSOR
MULTI- FUNCTION CENTER CONSOLE SWITCH
NCA WIRE
PARK BRAKE CONTROL SWITCH
RADIO
RIGHT CARGO LAMP
RIGHT COOLING FAN DIODE
RIGHT REAR SIDE MARKER LAMP
RIGHT REAR TURN SIGNAL LAMP
RIGHT STOP LAMP
RIGHT TAIL LAMP ASSEMBLY
SPORT MODE SWITCH
TRANS- MISSION SHIFT LEVER
TRANS- MISSION SHIFT LEVER POSITION INDICATOR
TRANSMISSION CONTROL MODULE
UNDERHOOD FUSE BLOCK
WHT WIRE
Go to component -> Ground distribution circuit (2 of 5) -> SPORT MODE SWITCH
Wiring diagram sport mode switch (3 of 3)
6 26 8 CHILD LOCKOUT IND HAZARD SW SIG LED BACKLIGHT DIMMING CTRL
9 12 17 LIGHTING CTRL SW SIG SURVEILLANCE SW SIG HAZARD LED DIMMING SIG
BLK WIRE
BODY CONTROL MODULE
BRN WIRE
CENTER CONSOLE MULTIFUNCTION SWITCH
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
GRY WIRE
HEADLAMP SWITCH
IND DIMMING CTRL
LED BACKLIGHT DIMMING CTRL
LOGIC INSTRUMENT CLUSTER
LOW SPD GMLAN SER DATA
NIGHT PANEL SWITCH
PARK BRAKE CONTROL SWITCH
PPL/WHT WIRE
SPORT MODE SWITCH
TRANSMISSION SHIFT LEVEL POSITION INDICATOR
WHT WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (1 of 2) -> SPORT MODE SWITCH
