Saab 9-4X I (2011-2011) rear body Wiring diagrams
This page contains all the electrical diagrams for the component. rear body, in which he is found in the car Saab 9-4X I (2011-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rear body (1 of 2)
BLK WIRE
DEFOGGER SYSTEM
DK BLU/WHT WIRE
DK GRN/WHT WIRE
DOWN
DRIVER OUTSIDE REARVIEW MIRROR
DRIVER PASSENGER
FUSE 27 FUSE BLOCK
GRY/BLK WIRE
HOT AT ALL TIMES
LEFT
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
OUTSIDE REARVIEW MIRROR SWITCH
PASSENGER
PASSENGER OUTSIDE REARVIEW MIRROR
REAR BODY
RED/WHT WIRE
RIGHT
TAN WIRE
WHT WIRE
Go to component -> Power mirror circuit -> REAR BODY
Wiring diagram rear body (2 of 2)
BATTERY FUSE BLOCK
BLK WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
DK BLU WIRE
DK GRN WIRE
FUSE
FUSE 5
FUSE BLOCK
HOT AT ALL TIMES
HOT AT ALL TIMES UNDERHOOD FUSE BLOCK FUSE 25
LEFT TRAILER STOP/ TURN SIGNAL LAMP RELAY
LH TRAILER TURN SIG LMP
ORG/ WIRE
PARK LMP RELY CTRL
REAR BODY
RED/BLK WIRE
RH TRAILER TURN SIG LMP
RIGHT TRAILER STOP/ TURN SIGNAL LAMP RELAY
TRAILER CONNECTOR
TRAILER PARK LAMPS RELAY
UNDERHOOD FUSE BLOCK
WHT WIRE
YEL WIRE
Go to component -> Trailer tow circuit -> REAR BODY
