Saab 9-4X I (2011-2011) re lic lp sply volt Wiring diagram
This page shows the only wiring diagram for the component.re lic lp sply volt, which is found in the car Saab 9-4X I (2011-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram re lic lp sply volt (1 of 1)
1 24 25 22 19 17 SIG GND HI SPD GMLAN SER DATA(-) HI SPD GMLAN SER DATA(+)
12 24 HAZ SW LH TURN SIG HAZ SW RH TURN SIG
13 7 26 BRK APLY SPLY VOL BRK APLY SENS SIG HAZ SW SIG
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/RED WIRE
DK GRN/WHT WIRE
ETC BRK SIG
FUSE
GMLAN LO SPD
HDLP SW PARK LPS SIG LOW REF HAZ SW DIMMING SIG
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
IGN
INSTRUMENT CLUSTER
LAMP
LEFT TURN IND
LOGIC
LT BLU WIRE
LT BLU/WHT WIRE
PARK LAMPS IND
PNK WIRE
PPL
PPL 12 13
PPL/WHT WIRE
RE LIC LP SPLY VOLT
RED/WHT WIRE
RIGHT FRONT PARK LAMP
RIGHT FRONT SIDE MARKER LAMP
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HEADLAMP
RIGHT REAR
RIGHT REAR SIDE MARKER
RIGHT STOP LAMP
RIGHT TAIL LAMP ASSEMBLY
RIGHT TURN IND
RIGHT TURN SIGNAL REPEATER LAMP
SER DATA
TAN WIRE
TAN/BLK WIRE
TURN SIGNAL LAMP
UNDERHOOD FUSE BLOCK
WHT WIRE
WHT/ DK BLU WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> RE LIC LP SPLY VOLT
