Saab 9-4X I (2011-2011) park auto Wiring diagram
This page shows the only wiring diagram for the component.park auto, which is found in the car Saab 9-4X I (2011-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram park auto (1 of 1)
AUTO
BLK WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL, SOUND SYSTEMS
DK BLU WIRE
DK GRN WIRE
FOG LAMP SWITCH
FRONT FOG LAMP IND
GROUND
HEAD PARK
HEADLAMP SWITCH
HIGH BEAM LAMP IND
INSTRUMENT CLUSTER
LEFT FRONT FOG LAMP
LOGIC
LOW SPD GMLAN SER DATA
LT BLU WIRE
LT GRN/BLK WIRE
NCA WIRE
OFF
OFF HEAD
PARK AUTO
PPL
RIGHT DAYTIME RUNNING LAMP
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP
RIGHT HEADLAMP BALLAST
RIGHT HIGH BEAM SOLENOID ACTUATOR
RIGHT LOW BEAM HEADLAMP
TAN/WHT WIRE
WHT WIRE
YEL WIRE
Go to component -> Headlamps circuit, with high intensity discharge (2 of 2) -> PARK AUTO
