Saab 9-4X I (2011-2011) nca Wiring diagrams

This page contains all the electrical diagrams for the component. nca, in which he is found in the car Saab 9-4X I (2011-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram nca (21 of 61)

Wiring diagram nca for Saab 9-4X I (2011-2011) (21 of 61)

Get access

BLK WIRE DOME DEFEAT DOME LAMP SWITCH DOME ON DRIVER DOOR COURTESY LAMP GRY WIRE INSTRUMENT PANEL COMPARTMENT LAMP LEFT REAR DOME/ READING LAMPS LEFT REAR DOOR COURTESY LAMP LEFT SUNSHADE NCA WIRE OFF ORG/ WIRE OVERHEAD CONSOLE DOME/ READING LAMPS PASSENGER DOOR COURTESY LAMP PPL RIGHT REAR DOME/ READING LAMPS RIGHT REAR DOOR COURTESY LAMP RIGHT SUNSHADE WHT WIRE

Go to component -> Courtesy lamps circuit (2 of 2) -> NCA WIRE

Wiring diagram nca (22 of 61)

Wiring diagram nca for Saab 9-4X I (2011-2011) (22 of 61)

Get access

ACCESSORY POWER RECEPTACLE REAR COMPARTMENT BLK WIRE CENTER TAIL LAMP DOME LAMP SWITCH DOME OVER- OVER- HEAD HEAD CONSOLE CONSOLE ACCENT READING LAMP LAMPS HIGH MOUNTED CENTER STOP LAMP INSIDE REAR VIEW MIRROR KEYLESS ENTRY CONTROL MODULE LEFT LEFT BACKUP LAMP LEFT CARGO LAMP LEFT LICENSE PLATE LAMP LEFT REAR DOME/ READING LAMPS LEFT REAR SIDE MARKER LAMP LEFT REAR TURN SIGNAL LAMP LEFT STOP LAMP LEFT TAIL LAMP ASSEMBLY LIFTGATE HANDLE SWITCH NCA WIRE PARKING BRAKE CONTROL MODULE PASSENGER AIR BAG DISABLE INDICATOR REAR BODY FUSE- REAR BLOCK WIPER RELAY REAR DEFOGGER GRID REAR WIPER MOTOR RIGHT BACKUP LAMP RIGHT LICENSE PLATE LAMP RIGHT REAR DOME/ READING LAMPS W/ POWER LIFTGATE PREMIUM AUDIO SOUND SYSTEM W/ REAR VIEW CAMERA W/O REAR VIEW CAMERA WHT WIRE

Go to component -> Ground distribution circuit (5 of 5) -> NCA WIRE

Wiring diagram nca (23 of 61)

Wiring diagram nca for Saab 9-4X I (2011-2011) (23 of 61)

Get access

1 2 RH FR DRL SPLY VOL LH FR DRL SPLY VOL 13 18 10 HDLP LW BEAM RLY CTRL HDLP HI BEAM RLY CTRL FOG LAMP RLY CTRL 22 11 16 HDLP SW PARK LP SIG AIR CONDITIONING SYSTEM AMBIENT LIGHT SENS SIG AMBIENT LIGHT/ SUNLOAD SENSOR BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE FRONT FOG LAMP FTP FUSE FUSE 50 FUSE 55 FUSE 56 FUSE HDLP OFF SIG CTRL HDLP SW ON SIG HDLP SW FLASH TO PASS SIG HEADLAMP HIGH BEAM RELAY HEADLAMP LOW BEAM RELAY HOT AT ALL TIMES BATTERY FUSE 5 FUSE BLOCK HVAC CONTROL MODULE LEFT DAYTIME RUNNING LAMP, LEFT HEADLAMP LEFT HEADLAMP BALLAST LEFT HIGH BEAM SOLENOID ACTUATOR LEFT LOW BEAM HEADLAMP LIGHTING CTRL SW REF LIGHTING CTRL SW SIG LOGIC LT BLU WIRE LT GRN/BLK WIRE LW SPD GMLAN SER DATA NCA WIRE PNK/WHT WIRE PPL PPL DIM SW PPL HDLP DIMMER SW HI BEAM SIG RED/BLK WIRE RELAY SIG GND TAN/WHT WIRE TURN SIGNAL/ MULTI-FUNCTION SWITCH UNDERHOOD FUSE BLOCK WHT WIRE YEL WIRE

Go to component -> Headlamps circuit, with high intensity discharge (1 of 2) -> NCA WIRE

Wiring diagram nca (24 of 61)

Wiring diagram nca for Saab 9-4X I (2011-2011) (24 of 61)

Get access

AUTO BLK WIRE COMPUTER DATA LINES SYSTEM CRUISE CONTROL, SOUND SYSTEMS DK BLU WIRE DK GRN WIRE FOG LAMP SWITCH FRONT FOG LAMP IND GROUND HEAD PARK HEADLAMP SWITCH HIGH BEAM LAMP IND INSTRUMENT CLUSTER LEFT FRONT FOG LAMP LOGIC LOW SPD GMLAN SER DATA LT BLU WIRE LT GRN/BLK WIRE NCA WIRE OFF OFF HEAD PARK AUTO PPL RIGHT DAYTIME RUNNING LAMP RIGHT FRONT FOG LAMP RIGHT HEADLAMP RIGHT HEADLAMP BALLAST RIGHT HIGH BEAM SOLENOID ACTUATOR RIGHT LOW BEAM HEADLAMP TAN/WHT WIRE WHT WIRE YEL WIRE

Go to component -> Headlamps circuit, with high intensity discharge (2 of 2) -> NCA WIRE

Wiring diagram nca (25 of 61)

Wiring diagram nca for Saab 9-4X I (2011-2011) (25 of 61)

Get access

BLK WIRE BRN WIRE DEFOGGER SYSTEM DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DK GRN/WHT WIRE DRIVER OUTSIDE REARVIEW MIRROR GRY WIRE GRY/BLK WIRE LEFT LOGIC LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/WHT WIRE MIRROR DIMMING NCA WIRE ORG/ WIRE ORG/BLK WIRE OUTSIDE REARVIEW MIRROR SWITCH PASSENGER OUTSIDE REARVIEW MIRROR PNK WIRE PNK/WHT WIRE PPL/WHT WIRE RIGHT TAN WIRE WHT WIRE YEL WIRE YEL/BLK WIRE

Go to component -> Memory mirrors circuit (2 of 2) -> NCA WIRE

Wiring diagram nca (26 of 61)

Wiring diagram nca for Saab 9-4X I (2011-2011) (26 of 61)

Get access

10 11 12 13 14 15 16 17 18 19 20 RESET SIG 18 19 PPL AUDIO SIG + BLK/WHT WIRE BRN WIRE CELLULAR PHONE NAVIGATION, DIGITAL RADIO ANTENNA COAX COMN SIG COMPUTER DATA LINES SYSTEM DATA BUS - DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DK GRN/WHT WIRE DRAIN WIRE DRAIN WIRE SCREEN SIG (+) PNK DVD SIG INF COMN SIG LH INF SIG LOW REF LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE NCA WIRE ORG/BLK WIRE PNK PPL WIRE PNK VOICE SIG WIRE PNK WIRE PNK/BLK WIRE PPL PPL SCREEN SIG (-) LF SPD SENS SIG PPL/WHT WIRE RADIO REAR SEAT CONTROL MODULE RED/WHT WIRE RH INF SIG SIG GND TAN WIRE TAN/WHT WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Navigation circuit, with amplifier (1 of 6) -> NCA WIRE

Wiring diagram nca (27 of 61)

Wiring diagram nca for Saab 9-4X I (2011-2011) (27 of 61)

Get access

18 19 PPL BLK/WHT WIRE BRIGHT CTRL BRN WIRE CELLULAR PHONE MICROPHONE (W/O ON STAR) DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DK GRN/WHT WIRE DRIVER SEATBACK VIDEO DISPLAY DVD COMN DVD SIG ENABLE SIG FUSE 20 GRY WIRE INF COMN SIG LF INF SIG LOW REF LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE MODULE SIG NCA WIRE ORG/BLK WIRE PHONE SIG PNK PPL WIRE PNK WIRE PNK/BLK WIRE PPL PPL/WHT WIRE REAR BODY FUSE BLOCK RED/WHT WIRE RH INF SIG RMOT SIG (-) SAVER RELAY ENERGIZED SIG GND TAN WIRE TAN/WHT WIRE W/ ENTERTAINMENT PACKAGE W/O ENTERTAINMENT PACKAGE WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Navigation circuit, with amplifier (2 of 6) -> NCA WIRE

Wiring diagram nca (28 of 61)

Wiring diagram nca for Saab 9-4X I (2011-2011) (28 of 61)

Get access

AUDIO/ VIDEO INPUT ADAPTER (W/ ENTERTAINMENT PACKAGE) AUX HIGH SIG BLK/WHT WIRE BRIGHT CTRL BRN WIRE COAX DISPLAY SIG + DK BLU WIRE DK BLU/WHT WIRE DK GRN/WHT WIRE DRAIN WIRE DRAIN WIRE (1) DRAIN WIRE DISPLAY SIG (-) DVD SIG 2 (+) ELECTRONIC BRAKE CONTROL MODULE ENABLE SIG FUSE 1 HOT W/ ACCESSORY RELAY ENERGIZED HOT W/ ACCESSORY RELAY ENERGIZED INSTRUMENT PANEL FUSE BLOCK FUSE 5 LH AUX SIG (1) LT BLU WIRE LT GRN WIRE MODE 2 SIGNAL NAVIGATION CONTROL MODULE (IF EQUIPPED) NCA WIRE ORG/BLK WIRE PASSENGER SEATBACK VIDEO DISPLAY (W/ ENTERTAINMENT PACKAGE) PNK PPL WIRE PNK WIRE PNK/BLK WIRE PPL PPL/WHT WIRE RED/WHT WIRE REMOTE SIG RESET SIG RH AUX SIG (1) SENS SIG SIG GND TAN WIRE TAN/WHT WIRE W/ NAVIGATION W/O AUDIO W/ AUDIO INTERFACE INTERFACE WHT WIRE YEL WIRE

Go to component -> Navigation circuit, with amplifier (3 of 6) -> NCA WIRE

Wiring diagram nca (29 of 61)

Wiring diagram nca for Saab 9-4X I (2011-2011) (29 of 61)

Get access

AUX AUDIO COMN SIG (2) AUX AUDIO COMN SIG (3) AUX AUDIO SCREEN (2) AUX DETECTION SIG AUXILIARY AUDIO INPUT BATT POS VOLT BLK/WHT WIRE CENTER RESET SIG CENTER SIG CENTER STACK SIG COMPUTER DATA LINES SYSTEM DATA HIGH DATA LOW DATA SHIELD DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DK GRN/WHT WIRE DRAIN WIRE (5) GMLAN SERIAL DATA GROUND GRY/WHT WIRE INFO DISPLAY MODULE LEFT AUX AUDIO SIG (3) LEFT AUX SIG (2) LINER NETWORK 10 LOW SPEED LT BLU WIRE LT GRN WIRE MULTIMEDIA PLAYER INTERFACE MODULE NCA WIRE NETWORK BUS 10 ORG/BLK WIRE PNK W/ NAVIGATION WIRE PNK W/O NAVIGATION WIRE PNK WIRE PPL/WHT WIRE RADIO/HVAC CONTROLS RED/WHT WIRE RESET SIG RIGHT AUX AUDIO SIG (3) RIGHT AUX SIG (2) SIG GND TAN WIRE TAN/WHT WIRE USB USB PNK WIRE W/ AUDIO INTERFACE W/ ENTERTAINMENT PACKAGE W/O AUDIO INTERFACE W/O ENTERTAINMENT PACKAGE WHT WIRE YEL WIRE

Go to component -> Navigation circuit, with amplifier (4 of 6) -> NCA WIRE

Wiring diagram nca (30 of 61)

Wiring diagram nca for Saab 9-4X I (2011-2011) (30 of 61)

Get access

AMPLIFIER CTRL AUDIO COMN SIG CENTER STACK AUDIO SIG (3) AUDIO SIG (3)/ (2) AUX AUDIO SIG (2) AUXILIARY AUDIO INPUT (W/ AUDIO INTERFACE) BATT POS VOLT BLK/WHT WIRE BODY CONTROL MODULE BRN WIRE BRN/WHT WIRE CENTER STACK HIGH COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE DOWN DRAIN WIRE GMLAN SERIAL DATA GRY WIRE GRY/WHT WIRE LADDER SIG 1 LF FRTDRAIN WIRE LF LO LVL AUDIO (-) LF LO LVL SIG LO LVL AUDIO SIG (-) LO LVL SIG (-) LOW REF LR DRAIN WIRE LR LO LVL AUDIO (-) LR LO LVL SIG LR SEAT AUDIO SIG LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/WHT WIRE NCA WIRE NETWORK BUS ORG/ WIRE ORG/BLK WIRE PNK WIRE RADIO RED/WHT WIRE REMOTE ENABLE SIG RF LO LVL SIG RIGHT AUX SIG (2) AUX DET SIG RIGHT AUX SIG (3) RIGHT STEERING WHEEL CONTROLS SWITCH RR LO LVL AUDIO (-) RR LO LVL SIG RR SEAT AUDIO SIG SEEK SRCE STACK LOW STACK RESET SIG STACK SHIELD STEERING WHEEL AIR BAG COIL SW REF TAN WIRE TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE (W/ ON STAR) USB USB PNK WIRE VOICE SIG VOL (-) WAKE UP SIG WHT WIRE YEL WIRE

Go to component -> Navigation circuit, with amplifier (5 of 6) -> NCA WIRE
