Saab 9-4X I (2011-2011) middle rear seat belt switch middle rear seat belt buckle Wiring diagram
This page shows the only wiring diagram for the component.middle rear seat belt switch middle rear seat belt buckle, which is found in the car Saab 9-4X I (2011-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram middle rear seat belt switch middle rear seat belt buckle (1 of 1)
1 1 RF HEAD CURTAIN MOD HI CTRL RF HEAD CURTAIN MOD LO CTRL
BRN WIRE
BRN/WHT WIRE
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
DRIVER SEAT BELT ANCHOR PRETENSIONER
DRIVER SEAT BELT RETRACTOR PRETENSIONER
DRIVER SEAT BELT SWITCH DRIVER SEAT BELT BUCKLE
GRY WIRE
GRY/BLK WIRE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE
LEFT REAR SEAT BELT SWITCH LEFT REAR SEAT BELT BUCKLE
LO REF LO REF PASS SEAT BELT SWITCH SIG
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/WHT WIRE
MIDDLE REAR SEAT BELT SWITCH MIDDLE REAR SEAT BELT BUCKLE
NCA WIRE
ORG/ WIRE
PASSENGER SEAT BELT ANCHOR PRETENSIONER
PASSENGER SEAT BELT RETRACTOR PRETENSIONER
PASSENGER SEAT BELT SWITCH PASSENGER SEAT BELT BUCKLE
PNK WIRE
PNK/BLK WIRE
PNK/WHT WIRE
PPL
PPL LH REAR SEAT BELT PRET CTRL LO REF
PPL/WHT WIRE
RIGHT REAR SEAT BELT SWITCH RIGHT REAR SEAT BELT BUCKLE
RIGHT ROOF RAIL AIR BAG
SEAT BELT BUCKLE PRETENSIONER
SHORTING BAR
TAN/BLK WIRE
TAN/ORG WIRE
TAN/WHT WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Supplemental restraints circuit (1 of 3) -> MIDDLE REAR SEAT BELT SWITCH MIDDLE REAR SEAT BELT BUCKLE
