Saab 9-4X I (2011-2011) medium speed cooling fan resistor Wiring diagrams
This page contains all the electrical diagrams for the component. medium speed cooling fan resistor, in which he is found in the car Saab 9-4X I (2011-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram medium speed cooling fan resistor (1 of 2)
BATT POSITIVE VOLT
BLK WIRE
BLOWER MOTOR
BLOWER MOTOR CONTROL MODULE
BLOWER MTR LOW REF
BLOWER MTR SPD CTRL
BODY CONTROL MODULE
COMPUTER DATA LINES SYSTEM
COOLING FAN MOTOR
DK BLU WIRE
DK GRN WIRE
ENGINE COOLANT TEMPERATURE SENSOR
FUSE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL FUSE BLOCK
LO SPD GMLAN SERIAL DATA
LOW SPEED COOLING FAN RESISTOR
LT BLU WIRE
MEDIUM SPEED COOLING FAN RESISTOR
NCA WIRE
ORG/ WIRE
PPL
RED/BLK WIRE
RED/WHT WIRE
SECURITY IND CTRL
TAN WIRE
YEL WIRE
Go to component -> 3.0l, automatic a/c circuit (3 of 4) -> MEDIUM SPEED COOLING FAN RESISTOR
Wiring diagram medium speed cooling fan resistor (2 of 2)
24 8 LOW REF ENG COOLANT TEMP SENS SIG
BLK WIRE
BLK/WHT WIRE
COMPUTER DATA LINES SYSTEM
COOLING FAN HI SPEED RELAY
COOLING FAN LO SPEED RELAY
COOLING FAN MEDIUM SPEED RELAY
COOLING FAN MOTOR
COOLING FAN RELAY
COOLING FAN SPEED CONTROL RELAY
DK BLU WIRE
DK GRN WIRE
ENGINE CONTROL MODULE
ENGINE CONTROLS
ENGINE COOLANT TEMPERATURE SENSOR
FUSE 41
FUSE 45
FUSE 5
GRY WIRE
HIGH SPEED COOLING FAN DIODE
HOT AT ALL TIMES
HOT AT ALL TIMES BATTERY FUSE BLOCK
IGNITION RELAY
LOW SPEED COOLING FAN DIODE
LOW SPEED COOLING FAN RESISTOR
LT BLU WIRE
MEDIUM SPEED COOLING FAN DIODE
MEDIUM SPEED COOLING FAN RESISTOR
NCA WIRE
RED/BLK WIRE
SIG GND
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK
YEL WIRE
Go to component -> 3.0l, cooling fan circuit -> MEDIUM SPEED COOLING FAN RESISTOR
