Saab 9-4X I (2011-2011) left headlamp ballast left high beam solenoid actuator Wiring diagram

1 2 RH FR DRL SPLY VOL LH FR DRL SPLY VOL 13 18 10 HDLP LW BEAM RLY CTRL HDLP HI BEAM RLY CTRL FOG LAMP RLY CTRL 22 11 16 HDLP SW PARK LP SIG AIR CONDITIONING SYSTEM AMBIENT LIGHT SENS SIG AMBIENT LIGHT/ SUNLOAD SENSOR BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE FRONT FOG LAMP FTP FUSE FUSE 50 FUSE 55 FUSE 56 FUSE HDLP OFF SIG CTRL HDLP SW ON SIG HDLP SW FLASH TO PASS SIG HEADLAMP HIGH BEAM RELAY HEADLAMP LOW BEAM RELAY HOT AT ALL TIMES BATTERY FUSE 5 FUSE BLOCK HVAC CONTROL MODULE LEFT DAYTIME RUNNING LAMP, LEFT HEADLAMP LEFT HEADLAMP BALLAST LEFT HIGH BEAM SOLENOID ACTUATOR LEFT LOW BEAM HEADLAMP LIGHTING CTRL SW REF LIGHTING CTRL SW SIG LOGIC LT BLU WIRE LT GRN/BLK WIRE LW SPD GMLAN SER DATA NCA WIRE PNK/WHT WIRE PPL PPL DIM SW PPL HDLP DIMMER SW HI BEAM SIG RED/BLK WIRE RELAY SIG GND TAN/WHT WIRE TURN SIGNAL/ MULTI-FUNCTION SWITCH UNDERHOOD FUSE BLOCK WHT WIRE YEL WIRE
