Saab 9-4X I (2011-2011) key cap/clmn lock sh pos sig tap up/tap down sw sig Wiring diagram
This page shows the only wiring diagram for the component.key cap/clmn lock sh pos sig tap up/tap down sw sig, which is found in the car Saab 9-4X I (2011-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram key cap/clmn lock sh pos sig tap up/tap down sw sig (1 of 1)
AUTOMATIC TRANSMISSION ASSEMBLY
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM)
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DRIVER INFORMATION CENTER DISPLAY
ENGINE CONTROL MODULE (ECM)
FUSE 19
FUSE 2
GEAR SHIFT POSITION SENSOR
HI SPD GMLAN SER DATA (+) SIG GND
HI SPD GMLAN SER DATA -
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
IGN VOLT IGN VOLTAGE
IGNITION CYLINDER LOCK CONTROL SWITCH
INSTRUMENT CLUSTER
KEY CAP/CLMN LOCK SH POS SIG TAP UP/TAP DOWN SW SIG
LEFT TRANSMISSION MANUAL SHIFT SWITCH
LINE PRESSURE CONTROL SOLENOID VALUE
LOGIC
LOGIC LOW SPD GMLAN SER DATA
LOW SPD GMLAN SER DATA
NCA WIRE
ORG/BLK WIRE
PNK 2 3 WIRE
PNK WIRE
PPL
PPL/WHT WIRE
PRESSURE CONTROL SOLENOID VALUE 1
PRESSURE CONTROL SOLENOID VALUE 2
PRESSURE CONTROL SOLENOID VALUE 3
PRESSURE CONTROL SOLENOID VALUE 4
RED/WHT WIRE
RIGHT TRANSMISSION MANUAL SHIFT SWITCH
SHIFT SOLENOID VALUE 1
SHIFT SOLENOID VALUE 2
STEERING WHEEL AIR BAG COIL
SYSTEM
TAN WIRE
TAN/BLK WIRE
TAP UP/TAP DOWN SW SIG PPL
TORQUE CONVERTER CLUTCH PRESSURE CONTROL SOLENOID VALUE
TRANS PARK/ NEUTRAL SIG HI SPD GMLAN SER DATA (-)
TRANSMISSION CONTROL MODULE
TRANSMISSION FLUID TEMPERATURE SENSOR
TRANSMISSION INPUT SHAFT SPEED SENSOR (ISS)
TRANSMISSION MANUAL SHIFT SWITCH
TRANSMISSION OUTPUT SHAFT SPEED SENSOR (OSS)
TRANSMISSION PARK/ NEUTRAL SIG
TRANSMISSION SHIFT LEVER
UNDERHOOD FUSE BLOCK
Go to component -> 2.8l turbo, a/t circuit -> KEY CAP/CLMN LOCK SH POS SIG TAP UP/TAP DOWN SW SIG
