Saab 9-4X I (2011-2011) center left rear instrument door panel speaker speaker Wiring diagrams
This page contains all the electrical diagrams for the component. center left rear instrument door panel speaker speaker, in which he is found in the car Saab 9-4X I (2011-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram center left rear instrument door panel speaker speaker (1 of 2)
8 7 6 5 4 3 2 1 SIG GND
AUDIO AMPLIFIER
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
CENTER LEFT REAR INSTRUMENT DOOR PANEL SPEAKER SPEAKER
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
FUSE
GRY WIRE
HOT AT ALL TIMES INSTRUMENT PANEL FUSE BLOCK
LEFT FRONT DOOR SPEAKER
LEFT FRONT TWEETER SPEAKER
LEFT REAR CARGO DOOR SPEAKER
LEFT/REAR SPEAKER -
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/WHT WIRE
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
RED/WHT WIRE
RIGHT FRONT RIGHT FRONT DOOR TWEETER SPEAKER SPEAKER
RIGHT REAR CARGO DOOR SPEAKER
RIGHT REAR DOOR SPEAKER
SUBWOOFER SPEAKER
TAN WIRE
W/ SURROUNDING AMPLIFIER
W/O ENTERTAINMENT PACKAGE, W/ NAVIGATION
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit, with amplifier (6 of 6) -> CENTER LEFT REAR INSTRUMENT DOOR PANEL SPEAKER SPEAKER
