Saab 9-4X I (2011-2011) brk apl sens sig brk apl sens sply vol Wiring diagram
This page shows the only wiring diagram for the component.brk apl sens sig brk apl sens sply vol, which is found in the car Saab 9-4X I (2011-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram brk apl sens sig brk apl sens sply vol (1 of 1)
2.8L 3.0L
ACCELERATOR PEDAL POSITION SENSOR
AUTOMATIC TRANSMISSION ASSEMBLY
BATT PSTN VOL
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE
BRAKE PEDAL POSITION SENSOR
BRK APL SENS SIG BRK APL SENS SPLY VOL
BRN WIRE
CES/ETC/TCC BRK SIG
COMPUTER DATA LINES SYSTEM
CRS CONT SW SIG
CRUISE
CRUISE IND
DK BLU WIRE
DK GRN WIRE
DRIVER INFORMATION CENTER DISPLAY
ENGINE CONTROL MODULE
FUSE 32
FUSE 5
GRY WIRE
HIGH SIGNAL
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
INSTRUMENT CLUSTER
LGT CONT SW REF
LOGIC
LOW GMLAN
LOW REF
LOW SIGNAL
LOW SPD GMLAN SRL DATA
LT BLU WIRE
LT BLU/WHT WIRE
NAVIGATION SYSTEM
NCA WIRE
PNK WIRE
PPL
PPL (OR 581) (OR 582)
RED/WHT WIRE
RES+
RIGHT STEERING WHEEL CONTROLS SWITCH
SER DATA
SET-
SIG GND
SL-
STEERING WHEEL AIR BAG COIL
TAN WIRE
TAN/BLK WIRE
TRANSMISSION CONTROL MODULE
TRANSMISSION CONTROL MODULE CONTROL SOLENOID VALVE ASSEMBLY
TRANSMISSION INPUT SHAFT SPEED SENSOR
TRANSMISSION OUTPUT SHAFT SPEED SENSOR
UNDERHOOD FUSE BLOCK
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Cruise control circuit -> BRK APL SENS SIG BRK APL SENS SPLY VOL
