Saab 9-4X I (2011-2011) 51 63 54 57 pnk ign starter enable relay cont Wiring diagram
This page shows the only wiring diagram for the component.51 63 54 57 pnk ign starter enable relay cont, which is found in the car Saab 9-4X I (2011-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 51 63 54 57 pnk ign starter enable relay cont (1 of 1)
2.8L
2.8L 3.0L
3.0L
51 63 54 57 PNK IGN STARTER ENABLE RELAY CONT WIRE
AUTOMATIC TRANSMISSION ASSEMBLY
BATTERY
BATTERY FUSE BLOCK
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH)
CHARGING CIRCUIT
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
FUSE 42
FUSE 5
FUSE 6
GRY WIRE
HOT W/ IGNITION MAIN RELAY ENERGIZED
IGN MODE SW
IGNITION MODE SWITCH
LO SPD GMLAN SERIAL DATA
LOGIC TRANSMISSION CONTROL MODULE (MOUNTED ON TOP OF TRANSMISSION)
LT BLU WIRE
LT GRN WIRE
LT GRN/WHT WIRE
ORG/BLK WIRE
PARK/NEUTRAL SIG (1)
PNK WIRE
PPL
PPL/WHT WIRE
RED WIRE
RED/BLK WIRE
STARTER MOTOR
STARTER RELAY
TAN WIRE
TAN/BLK WIRE
TRANSMISSION CONTROL MODULE
TRANSMISSION INTERNAL MODE SWITCH
UNDERHOOD FUSE BLOCK
WHT WIRE
Go to component -> Starting circuit -> 51 63 54 57 PNK IGN STARTER ENABLE RELAY CONT WIRE
