Courtesy lamps circuit, sedan for Saab 9-3 II (2002-2008)

1 T-B 3 2 R-B 7 3 T-D 1 R-B BCM BLK (OR BRN/BLU) WIRE BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/YEL WIRE BOOT LID CENTRAL LOCKING MODULE COMPUTER DATA LINES SYSTEM DRIVER'S DOOR CONTROL MODULE (IN DRIVER'S FRONT DOOR) DRIVER'S DOOR FOOTWELL LAMP DRIVERS DOOR CENTRAL LOCKING UNIT FRONT DOME LAMP MODULE FUSE 12 FUSE 5 FUSE 8 FUSE 15 FUSE 9 FUSE 7 GLOVE BOX LAMP) GRN (OR GRY) WIRE GRN (OR RED/WHT) WIRE GRN WIRE GRN/GRY WIRE GRY WIRE HOT AT ALL TIMES INSTRUMENT PANEL ELECTRICAL CENTER (ON LEFT SIDE OF DASH) INTERIOR LIGHT RELAY LEFT FRONT FOOTWELL LAMP LEFT REAR DOOR CENTRAL LOCKING UNIT LEFT REAR DOOR CONTROL MODULE (IN LEFT REAR DOOR) LEFT VANITY MIRROR LUGGAGE COMPARTMENT LAMP PASSENGER'S DOOR CENTRAL LOCKING UNIT REAR DOME LAMP MODULE REAR ELECTRICAL CENTER (LEFT SIDE OF LUGGAGE COMPT) RED RED/GRN WIRE RED WIRE RED/GRY (OR RED/VIO) WIRE RED/GRY WIRE RED/WHT WIRE RIGHT FRONT FOOTWELL LAMP RIGHT REAR DOOR CENTRAL LOCKING UNIT RIGHT REAR DOOR CONTROL MODULE (IN RIGHT REAR DOOR) RIGHT VANITY MIRROR T-A 4 5 VIO WIRE WHT WIRE YEL WIRE YEL/GRY WIRE
