Rear fog lamps circuit for Saab 9-3 II (2002-2008)
Rear fog lamps circuit
BLK WIRE
BLU WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (IN DASHBOARD MAIN FUSE BOX)
COMPUTER DATA LINES SYSTEM
FUSE 26
GRN WIRE
HOT AT ALL TIMES
LEFT BOOT LID LAMP CLUSTER UNIR (FOG LAMP)
LEFT REAR BOOT LID LIGHT CLUSTER UNIT
LIGHT SWITCH UNIT
MAIN INSTRUMENT UNIT
R-B
REAR ELECTRICAL CENTER (LEFT SIDE OF LUGGAGE COMPT)
RIGHT REAR BOOT LID LIGHT CLUSTER UNIT
SEDAN
T-C
T-D
WAGON
YEL/GRY WIRE
