Saab 9-3 II (2002-2008) 2.0l turbo, automatic a/c circuit, single fan

1 2 (CONVERTIBLE) (EXCEPT CONVERTIBLE) 2 3 A/C COMPRESSOR A/C COMPRESSOR RELAY A/C PRESSURE SENSOR (NEAR LEFT FRONT CORNER OF AIR FILTER) ACC CONTROL MODULE BLK WIRE BLK/BLU (OR BLU/WHT) WIRE BLK/BLU WIRE BLU (OR GRN) (OR BLU/WHT) WIRE BLU WIRE BLU/GRY WIRE BLU/VIO WIRE BLU/WHT WIRE BODY CONTROL MODULE (IN DASHBOARD MAIN FUSE BOX) BRN WIRE BRN/GRY WIRE BRN/ORG WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM COOLANT TEMPERATURE SENSOR (AT FRONT LEFT SIDE OF ENGINE) ELECTRICAL CENTER (IN FRONT OF BATTERY) EXTERIOR LIGHTS SYSTEM SEATS SYSTEM FRONT ROOF LAMP UNIT FUSE 3 GRN (OR BLU/BLK) (OR BLK/BLU) WIRE GRN WIRE GRN/BLU WIRE GRN/VIO WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOUSING) INSTRUMENT CLUSTER SYSTEM INSTRUMENT PANEL ELECTRICAL CENTER (ON LEFT SIDE OF DASH) FUSE 4 MAXI FUSE MAXI FUSE 35 NCA WIRE OUTDOOR TEMPERATURE SENSOR (UNDER CENTER OF FRONT BUMPER) RADIATOR FAN MOTOR RADIATOR FANS RELAY UNIT (ON TOP OF RADIATOR FAN COVER) RED/GRN WIRE RED/GRY WIRE SEATS SYSTEM SID- SUN SENSOR (TOP OF DASH) TRIONIC CONTROL MODULE (RIGHT FRONT OF ENGINE COMPT) UNDERHOOD ELECTRICAL CENTER (LEFT SIDE OF ENGINE BAY) VENTILATION FAN CONTROL UNIT (ON FAN MOTOR HOUSING) VENTILATION FAN MOTOR (ON UNDERSIDE OF FAN HOUSING) WHT WIRE WHT/GRY WIRE YEL/BLU WIRE YEL/GRY WIRE YEL/VIO WIRE

ACC CONTROL MODULE AIR RECIRCULATION FLAP MOTOR (ON OUTER FAN HOUSING END PLATE) BLK/BLU WIRE BLK/GRY WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE FLOOR AIR DISTRIBUTION MOTOR GRN/BLK WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/VIO WIRE GRN/WHT WIRE GRY WIRE GRY/BRN WIRE GRY/YEL WIRE LEFT AIR MIXING DAMPER MOTOR (ON LEFT SIDE OF HEATING, VENTILATION UNIT) LEFT FLOOR MIXED AIR TEMPERATURE SENSOR LEFT PANEL MIXED AIR TEMPERATURE SENSOR (IN AIR DUCT) RED/WHT WIRE RIGHT AIR MIXING DAMPER MOTOR (ON RIGHT SIDE OF HEATING, VENTILATION UNIT) RIGHT FLOOR MIXED AIR TEMPERATURE SENSOR RIGHT PANEL MIXED AIR TEMPERATURE SENSOR (IN AIR DUCT) VIO/GRN WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE
