Saab 9-3 II (2002-2008) tailgate/boot lid switch Wiring diagrams
This page contains all the electrical diagrams for the component. tailgate/boot lid switch, in which he is found in the car Saab 9-3 II (2002-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
tailgate/boot lid switch wiring diagram (1 of 2)
BLK WIRE
BLU/GRY WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (IN DASHBOARD MAIN FUSE BOX)
BOOT LID CENTRAL LOCKING MODULE
BOOT LID HANDLE MODULE
BRN WIRE
BRN/GRY WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL MODULE (IN DRIVER'S FRONT DOOR)
FILLER FLAP SOLENOID (NEAR FUEL TANK FILLER FLAP IN LUGGAGE COMPT)
GRN WIRE
GRN/BLU WIRE
GRY WIRE
GRY/WHT WIRE
INTEGRATED CONTROL MODULE
ORG/ WIRE
R-A
R-B
REAR ELECTRICAL CENTER (LEFT SIDE OF LUGGAGE COMPT)
T-A
T-B
T-C
T-D
TAILGATE/BOOT LID SWITCH
WHT WIRE
Go to component -> Trunk, tailgate, fuel door circuit, 5 door -> TAILGATE/BOOT LID SWITCH
tailgate/boot lid switch wiring diagram (2 of 2)
4 DOOR
BLK WIRE
BLU/GRY WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (IN DASHBOARD MAIN FUSE BOX)
BOOT LID CENTRAL LOCKING MODULE
BOOT LID HANDLE MODULE
BOOT LID OPENING MOTOR RELAY
BRN WIRE
BRN/GRY WIRE
BRN/VIO) WHT (OR WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL MODULE (IN DRIVER'S FRONT DOOR)
FILLER FLAP SOLENOID (NEAR FUEL TANK FILLER FLAP IN LUGGAGE COMPT)
GRN WIRE
GRY WIRE
GRY/WHT WIRE
INTEGRATED CONTROL MODULE
PNK WIRE
R-A
R-B
REAR ELECTRICAL CENTER (LEFT SIDE OF LUGGAGE COMPT)
RED/GRY WIRE
T-A
T-B
T-C
T-D
TAILGATE/BOOT LID SWITCH
VIO WIRE
WHT WIRE
Go to component -> Trunk, tailgate, fuel door circuit, except 5 door -> TAILGATE/BOOT LID SWITCH
