Backup lamps circuit for Saab 9-3 I (1998-2003)
Backup lamps circuit
A/T
BLK WIRE
BLK/BRN WIRE
BLK/WHT WIRE
BRN/WHT WIRE
DICE CONTROL MODULE (ABOVE INTERIOR RELAY BLOCK)
FUSE 31
HOT IN RUN
INTERIOR FUSE BLOCK (BEHIND LEFT END OF DASH)
LEFT FRONT LAMP CLUSTER SIDE REVERSE LIGHT
LEFT REVERSING LIGHT LAMP
M/T
NCA WIRE
RED WIRE
REVERSING LIGHT RELAY (ON INTERIOR RELAY BLOCK)
REVERSING LIGHT SWITCH (ON GEAR- BOX)
RIGHT FRONT LAMP CLUSTER SIDE REVERSE LIGHT
RIGHT REVERSING LIGHT LAMP
TRANSMISSION RANGE SWITCH 2 (ON TRANS- MISSION)
WHT WIRE
