Saab 9-3 I (1998-2003) simultaneous central locking switch (except convertible) wiring diagram
This page shows the only wiring diagram for the component.simultaneous central locking switch (except convertible), which is found in the car Saab 9-3 I (1998-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
simultaneous central locking switch (except convertible) wiring diagram (1 of 1)
BLK WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/YEL WIRE
CENTRAL LOCKING SYSTEM FUEL FILLER CAP SOLENOID (NEAR TO FUEL DOOR)
DRIVER'S CENTRAL LOCKING MOTOR (IN DRIVER'S DOOR)
DRIVER'S DOOR CENTRAL LOCKING MICROSWITCH (IN DRIVER'S DOOR)
EXCEPT CONVERTIBLE
HOT AT ALL TIMES
INTERIOR FUSE BLOCK (BEHIND LEFT END OF DASH) FUSE 25
LEFT REAR CENTRAL LOCKING MOTOR (EXCEPT CONVERTIBLE) (IN LEFT REAR DOOR)
NCA WIRE
ORG/ WIRE
PASSENGER'S CENTRAL LOCKING MOTOR (IN PAS- SENGER'S DOOR)
RED WIRE
RED/VIO WIRE
RIGHT REAR CENTRAL LOCKING MOTOR (EXCEPT CONVERTIBLE) (IN RIGHT REAR DOOR)
SIMULTANEOUS CENTRAL LOCKING SWITCH (EXCEPT CONVERTIBLE)
TWICE CONTROL MODULE (UNDER DRIVER'S SEAT)
VIO WIRE
VIO/WHT WIRE
YEL/BLU WIRE
YEL/GRY WIRE
Go to component -> Power door lock circuit -> SIMULTANEOUS CENTRAL LOCKING SWITCH (EXCEPT CONVERTIBLE)
